1-1/2" Brass Ball Valve, 2 Piece

The valve body is made of high-quality brass forging to prevent leakage. Brass ball valve is manufactured by a high-precision special machine with low flow resistance. The medium inside the valve body has a straight channel, and the medium flows in a straight line.

Specification

• Model: ATO-BBV-DN40
• Nominal Diameter: DN40
• Nominal Pressure: 1.6MPa
• Size: 1-1/2 inch
• Body Material: Brass
• Connection Type: Thread
• Standard: Compliant with ISO 228 Standard
• Structure: Fixed Ball Valve
• Applicable Temperature: -10℃≤T≤120℃
• Valve Action: Flow Control
• Mode of Action: Double Acting
• Channel Location: Straight
• Sealing Material: Rubber
• Sealing Method: Soft Seal
• Drive Mode: Manual
• Flow Direction: Bidirectional
• Working Medium: Water, Oil, Non-Corrosive and Non-Combustible Gas
• Weight: 860g

Dimensions & Details (Unit: mm)

Tips: Brass ball valve advantages

1. Open and close without friction. This function completely solves the problem that the traditional valve will affect the sealing due to the friction between the sealing surfaces.
2. Top-loading structure. The valve installed on the pipeline can be directly inspected and maintained online, which can effectively reduce the shutdown of the device and reduce the cost.
3. Single valve seat design. It eliminates the problem that the medium in the cavity of the valve affects the safety of use due to abnormal pressure increase.
4. Low torque design. The valve stem with special structure design can easily open and close the valve with only a small handle.
5. Wedge-shaped sealing structure. The valve relies on the mechanical force provided by the valve stem to press the ball wedge onto the valve seat to seal, so that the sealing performance of the valve is not affected by the change of pipeline pressure difference, and the sealing performance is reliably guaranteed under various working conditions.
6. Self-cleaning structure of sealing surface. When the ball is tilted away from the valve seat, the fluid in the pipeline passes 360° evenly along the sealing surface of the ball, which not only eliminates the local scouring of the valve seat by the high-speed fluid, but also washes away the accumulation on the sealing surface to achieve the purpose of self-cleaning.
