LVDT displacement sensor combines sensor, oscillator, demodulator and filter in one, large stroke, high accuracy, good stability, anti-interference ability, high temperature resistance, non contact measurement, easy to install.
Draw wire sensor combines the advantages of angular sensor and linear displacement sensor, has a small mounting size, compact structure and high precision. The measuring range can be 1000mm/2500mm/5000mm or even 50000mm.
Linear displacement sensor housing surface anodized, built-in conductive plastic measurement unit, anti-corrosion, no temperature drift, long service life, automatic electrical grounding, suitable for most common applications.
Linear displacement sensor has two miniature hinges at both ends, built-in conductive plastic measurement unit, housing surface anodized, anti-corrosion, no temperature drift, especially suitable for the occasions with small installation space, swing motion, and sensor body can't be fixed.
Single point load cell is widely used for weighing scale or pricing scale. Single point load cell is suited to use in flat and low space, with parallel beam structure, good stability, good output symmetry, high accuracy, low temperature drift and overload protection.
Aluminum alloy rail type magnetostrictive displacement sensor for measuring linear displacement, external installation, compact structure, easy to use, good security, suitable for CNC machinery worked in large vibration.
Non contact displacement sensor for hydraulic servo cylinder, high precision, no temperature drift, anti-jamming performance, long life, high temperature resistance, corrosion resistance, high pressure resistant.
AC voltage transducers are input/output/power supply isolated voltage transducers, with measuring range from 10V/50V/100V/200V/300V to 500V, wide power supply voltage AC/DC 85V~265V, work temperature -25~+70℃, frequency range 25Hz ~ 1kHz, and strong anti-interference capability.
Current sensors are AC/DC universal current sensors, with a low current measuring range from milliamp current 0.1mA to 5A. AC/DC current sensors adopt linear photoelectric isolation or modulation and demodulation principle, fast response, 0.5%FS high accuracy, good stability, small size, light weight, input current terminal connection, DIN rail installation. Isolated current sensors are widely used for AC sine wave current or DC bidirectional current measurement.
Low cost M5 laser sensor adopts diffuse reflection or through beam detection mode, has 304 stainless steel detection head with thread size M5*0.5mm, laser spot size 1mm, protection class IP67, can be used for distance, height, displacement, position, speed and level measurement. The M5 diffuse reflection laser sensor has 200mm detection range, while the through beam laser sensor has the detection range of 50m.
This series of pressure sensors use a high-performance silicon piezoresistive pressure core as core element. The internal ASICs convert the mV signal into a standard current (4-20mA/0-20mA), voltage (0-5V/1-5V/0-10V) or RS485 signal. Pressure sensor with stainless steel sealing structure has small size, light weight, high anti-vibration and anti-shock performance, measuring range -0.1~100MPa/ -1~1000bar/ -14~14503psi, medium temperature -40~+60℃ (-40~+140℉), for air/water/oil pressure measurement.
4mm proximity sensor can detect a variety of metals, miniature size, long life, low price, shielded type installation, anti-interference ability, 1mm detection distance, using for precise positioning of molds, precision machine tools and robots.
Torque sensor is a strain gauge sensor for static torque measurement. Static torque sensor has double-flange, a 5 pin male plug and no mounting base so it can be easy to install. Reaction torque sensors have a capacity range from 20 Nm/300 Nm/2000 Nm to 10000 Nm and can measure both forward and reverse torque.
Signal isolator ATO-SIGNI-402E series is a universal signal isolator that can be customized with various active and passive input signals and output signals, such as thermocouple K/B/S/E type, RTD Pt100, current 4-20mA/0-20mA and voltage 0-5V/1-5V/0-10V. Signal isolator has pluggable terminals, 12.5mm thickness, high accuracy 0.1%FS and protection class IP20.
Submersible level sensor adopts 304 stainless steel housing and waterproof cable, can be put in water/oil/fuel tank or reservoir directly for liquid level measurement. The measuring range can be 0-1m/0-3m/0-5m/0-10m ~ 0-200m. Liquid level sensor has optional accuracy 0.5%FS or 0.3%FS, output signal 4-20mA/0-5V/RS485, power supply DC 24V/12V. The cable type and connection type are also customizable.
DHT11 temperature and humidity sensor includes a resistive humidity sensor and a NTC temperature sensor, built-in one high-performance 8-bit SCM, one-wire communication mode, with small size, excellent quality, fast response, strong anti-interference ability, low price, long signal transmission distance.
Sheath thermocouple have shielded thermocouple wire of common length 500mm and sheath diameter Ф3~Φ8mm, with flexibility, high pressure resistant, fast thermal response time and long operating life. K type thermocouple can directly measure the temperature of liquid, vapor, gas medium and solid surface in the range of 0~950 ℃ in various production processes.
