Low cost laser distance sensor online for sales, laser spot size 1mm*3mm, measuring range 30-100mm, protection class IP67, 650nm red laser, it can be used in reel production monitor, solar panel warpage measurement, control movement of robot arm, small pack missing detection.
Low cost M5 laser sensor adopts diffuse reflection or through beam detection mode, has 304 stainless steel detection head with thread size M5*0.5mm, laser spot size 1mm, protection class IP67, can be used for distance, height, displacement, position, speed and level measurement. The M5 diffuse reflection laser sensor has 100mm detection range, while the through beam laser sensor has the detection range of 50m.
High precision laser distance sensor with load current 200mA, measuring center distance 30mm, response time 2ms/ 16ms/ 40ms can be configurable, laser spot size Φ0.5@30mm, two output signals are optional. It has advantages of light weight, long service life.
High precision laser sensor has 304 stainless steel detection head and plastic protective sleeve, thread size M6*0.5mm, fast response time 0.1ms, laser spot size 1.2mm, can be used for speed, depth, length, displacement, position measurement. The diffuse reflection M6 laser sensor has 150mm detection range, while the through beam laser sensor has the linear detection range of 50m.
M8 laser sensor with laser spot size 1mm can be used for industrial automation control, such as measuring the object position, length and height, or detecting the motor speed. M8 laser sensor has diffuse reflection/through beam detection mode and NPN/PNP NO/NC output mode for selection, thread size M8*1mm, protection class IP67. The diffuse reflection type and through beam type laser sensor have respective detection range of 150mm/50m.
Factory price laser distance sensor with laser spot size Φ2.5mm@500mm, protection class IP67, measuring range 80-500mm, can be used for reel production monitor, solar panel warpage measurement, control movement of robot arm, small pack missing detection.
M12 laser sensor for displacement/rpm measurement adopts diffuse reflection or through beam detection mode. The through beam laser sensor has the detection range of 100m, and the diffuse reflection laser sensor has 200mm detection range. High accuracy laser sensor has power supply 10-30VDC, protection class IP67, laser spot size 4mm and stainless steel detection head with thread size M12*1mm.
Economical price laser distance sensor with small outer size 65*51*23mm, measuring range 150-1000mm, spot diameter Φ3mm@1000mm, power supply 10-30V DC/ 12-24V DC, protection class IP67, RS-485 (Support Modbus protocol)/ 4-20mA (Load resistance< 390Ω) two output signals can be chosen.
Cylindrical M18 laser sensor adopts diffuse reflection detection mode, with stainless steel housing (thread size M18*1.5mm), laser spot size 4mm, fast response time 0.1ms, optional output mode NPN/PNP NO/NC, protection class IP67, can be used for vibration measurement, or object thickness/ flatness detection. The maximum detection range of M18 diffuse reflection laser sensor is 300mm.
Low price laser sensor has rectangular ABS housing with small outer size 22*11*31mm, laser spot size 1mm, power supply 10-30VDC, protection class IP67, can be used for object presence/ distance/ contour measurement, material/ liquid level detection and control, linearity correction, vehicle wheel speed/ vibration/ bounce measurement. The rectangular diffuse reflection type and through beam type laser sensor have respective detection range of 200mm/50m.
A laser sensor is a sensor that uses laser technology to measure. It consists of laser device, laser detector and measurement circuit. Laser sensors are often used to measure physical quantities such as displacement, length, thickness, distance, vibration, speed, etc., and can also be used for monitoring of atmospheric pollutants and flaw detection.
Laser sensor for length/height/thickness measurement In the high-precision machinery manufacturing industry and the optical processing industry, the length/height/thickness measurement is mostly carried out by using the interference phenomenon of light waves, and its accuracy mainly depends on the monochromaticity of the light. As the most ideal light source, laser is purer than the best monochromatic light source in the past, so the laser sensor can obtain a larger measuring range and higher precision.
Laser sensor for distance measurement The principle of laser ranging is to measure the round-trip time after the laser is aimed at the target and then multiplied by the speed of light to obtain the round-trip distance. Because the laser has the advantages of high directivity, high monochromaticity and high power, these are critical for measuring large distances, determining target orientation, improving the signal-to-noise ratio of the receiving system, and ensuring measurement accuracy.
Types of Laser Sensor
Laser sensors are often used to measure physical quantities such as length, distance, vibration, speed, and orientation. They can also be used for flaw detection and monitoring of atmospheric pollutants. The application fields are becoming more and more extensive. Two types of laser sensors are described below.
Laser Displacement Sensor
The laser displacement sensor can realize non-contact long-distance measurement by utilizing the high directivity, high monochromaticity and high brightness of the laser. Laser displacement sensor (also called magnetostrictive displacement sensor) is a new type of measuring instrument. Its appearance greatly improves the accuracy and reliability of displacement measurement, and also provides an effective measurement method for non-contact displacement measurement.
Laser Distance Sensor
Laser ranging is actually an active optical detection method. The detection mechanism of active optical detection is: the detection system emits a beam (in optical detection, generally infrared or visible light) to the target, and the beam is radiated by the target surface to generate an echo signal. The echo signal contains the information to be measured directly or indirectly. The receiving and signal processing system obtains the measured quantity by receiving and analyzing the echo signal. The principle of the laser ranging sensor is the same as that of the wireless radar. After the laser is aimed at the target and launched, its round-trip time is measured, and then multiplied by the speed of light to obtain the round-trip distance. When measuring the distance, the laser rangefinder can accurately determine the target orientation, so it has been paid more and more attention.
The difference between a laser sensor and a photoelectric sensor
Working Principle: The photoelectric sensor mainly converts the change of light intensity into the change of electrical signal, so as to achieve the control of light. First, a laser diode is used to irradiate the target with laser pulses. The laser light is reflected by the target and scattered in all directions. A portion of the light is reflected back to the sensor receiver, where it is imaged by the optics and converted into a corresponding electronic signal.
Light source: Light sensors have a light source that sees red and red light, while laser sensors use laser technology. Red and red light spots are relatively large, and the farther away, the harder it is to detect smaller things, because the laser is generated by the laser, and the size of the source changes with the distance, and The general laser is different, its light spot will be very small, and it will become bigger and bigger as time goes by, but this change is so small that it cannot be detected by the naked eye. will zoom in.
Application: Laser sensors are widely used in presence, absence, positioning, counting, concave-convex, front and back, etc., and are widely used in packaging, electronics and other fields. Photoelectric sensors are used in crop position detection, liquid level control, product counting, width recognition, speed detection, fixed-length cutting, hole recognition, signal delay, automatic door detection, color mark detection, punching and shearing machines, and safety protection. In addition, using the infrared stealth feature, it can be used as anti-theft and alert in banks, warehouses, shops, offices and other needs.
