    1 Pole Miniature Circuit Breakers

    View as Grid List
    Display per page
    Sort by

    1 amp 1 pole Miniature Circuit Breaker

    $57.49
    SKU: ATO-MCB-1P01
    1 pole miniature circuit breaker MCB is a mini electrical switch with 1 amp current. It can safely be used in AC 50Hz, 230/400V with a 6 kA rated short-circuit breaking capacity, providing an electrical circuit from damage caused by overload or short circuits.

    2 amp 1 pole Miniature Circuit Breaker

    $55.81
    SKU: ATO-MCB-1P02
    Favorable price 1 pole miniature circuit breaker with 2 amp rated current, DIN rail mounting, can safely be used in AC 50Hz, 230/400V with a 6 kA rated short-circuit breaking capacity, providing an electrical circuit from damage caused by overload or short circuits.

    3 amp 1 pole Miniature Circuit Breaker

    $57.49
    SKU: ATO-MCB-1P03
    Factory price single pole miniature circuit breaker is an electrical switch with a 3A current rating that offers optimum and efficient protection for branch and control circuits. The 6kA rated short-circuit breaking capacity of this 1 pole mini MCB breaker makes it ideal for commercial and industrial applications.

    4 amp 1 pole Miniature Circuit Breaker

    $57.49
    SKU: ATO-MCB-1P04
    4 amp single pole miniature circuit breaker with standard ratings of 6kA rated short-circuit breaking capacity at 230/400V AC single voltage, standard 35 mm DIN rail mounting. The mini MCB circuit breaker has a c curve trip characteristic to suit most applications.

    6 amp 1 pole Miniature Circuit Breaker

    $55.19
    SKU: ATO-MCB-1P06
    Single pole C6 MCB miniature circuit breaker is an electrical switch that provides an electrical circuit from damage caused by overload or short circuits, with a 6 amp current rating, used in AC 50Hz, 230/400V with a 6 kA short circuit withstand rating.

    10 amp 1 pole Miniature Circuit Breaker

    $52.99
    SKU: ATO-MCB-1P10
    Favorable price compact miniature circuit breaker with 1 pole, 10A current rating, and rated short-circuit breaking capacity of 6 kA at 230/400V AC. C type tripping curve, easy installation on DIN rail. This mini MCB is suitable for supplementary protection.

    16 amp 1 pole Miniature Circuit Breaker

    $52.99
    SKU: ATO-MCB-1P16
    Economical price C16 miniature circuit breaker is intended for short circuit and overload protection in the AC 50Hz circuit, 230/400V single pole voltage, and a rated current of 16 amp. This single mini MCB with 6kA rated impulse withstand voltage meets commercial and industrial applications.

    25 amp 1 pole Miniature Circuit Breaker

    $53.99
    SKU: ATO-MCB-1P25
    Single pole miniature circuit breaker (MCB) with a 25A current rating, featuring C-curve trip characteristics compliant with IEC standards. This mini circuit breaker offers 6 kA rated impulse withstand voltage for its micro design, providing reliable protection against overloads and short circuits in electrical conductors.

    32 amp 1 pole Miniature Circuit Breaker

    $54.29
    SKU: ATO-MCB-1P32
    ATO C32 1 pole MCB miniature circuit breaker is a micro electrical switch to turn off the electrical circuit during a faulty condition to protect conductors. This mini circuit breaker with a 32 amp current rating, is used in AC 50Hz, 230/400V with a 6 kA short circuit withstand rating.

    40 amp 1 pole Miniature Circuit Breaker

    $54.99
    SKU: ATO-MCB-1P40
    Low single pole cost miniature circuit breaker is 35mm DIN rail mounted, 40 amp rated current at 230/400V AC voltage, 6kA short circuit breaking capacity. The 1 pole mini MCB breaker offers a compact solution for protection requirements.

    50 amp 1 pole Miniature Circuit Breaker

    $58.49
    SKU: ATO-MCB-1P50
    Favorable price 1 pole miniature circuit breaker for sale, with short circuit protection, overload protection and circuit break protection functions, 50 amp rated current, DIN rail mounting, is an electrical switch to turn off the electrical circuit during a faulty condition to protect conductors.

    63 amp 1 pole Miniature Circuit Breaker

    $57.99
    SKU: ATO-MCB-1P63
    Use a C63 single pole miniature circuit breaker in a low voltage electrical network. Low cost mini MCB with 63 amp current rating, used in AC 50Hz, 230/400V with a 6 kA short circuit withstand rating, is more sensitive to overcurrent and a reliable way to protect conductors.

    A 1 pole miniature circuit breaker (MCB) is an electrical switch designed to protect electrical circuits from overload and short circuits. It consists of a single pole, which means it can interrupt the flow of current in one conductor. The MCB is typically installed in residential, commercial, and industrial electrical distribution panels.

    The micro circuit breaker operates on the principle of thermal and magnetic tripping mechanisms. It has a bimetallic strip that heats up due to the flow of current, and when the current exceeds the rated value, the strip bends and trips the circuit breaker, interrupting the current flow. Additionally, the MCB has a magnetic coil that responds to high-current surges, such as those caused by short circuits, and quickly trips the breaker to protect the circuit.

    ATO provides 1 amp, 2 amp, 3 amp, 4 amp, 6 amp, 10 amp, 16 amp, 25 amp, 32 amp, 40 amp, 50 amp, 63 amp single pole mini circuit breaker with 6kV rated short-circuit breaking capacity and C curve characteristic. This 1 pole MCB is compact in size and easy to install. It is equipped with a toggle switch for manual control, allowing users to turn the circuit on or off. The 1P MCB is an essential component in electrical systems, ensuring the safety and protection of circuits from overloads and faults.
