6 amp 1 pole Miniature Circuit Breaker

5 out of 5 based on 2 reviews | Write a review

$55.19

Single pole C6 MCB miniature circuit breaker is an electrical switch that provides an electrical circuit from damage caused by overload or short circuits, with a 6 amp current rating, used in AC 50Hz, 230/400V with a 6 kA short circuit withstand rating.

SKU: ATO-MCB-1P06

Qty:

30-day Returns

Free Shipping

Delivery date: 6-12 days

Overview
Related Video

C6 single pole miniature circuit breaker (MCB) is a micro electrical safety switch for protecting electrical circuits from overloads and short circuits. This mini circuit breaker handles 6A current and is commonly used in residential, commercial, and industrial applications.

Single Pole MCB Breaker Information

Rated Current: 6 amp
Rated Voltage: 230/400V AC, 50Hz
Number of poles: 1 pole
6 kA rated short-circuit breaking capacity
Compliant with IEC standard
C curve trip characteristic
With overload protection and short circuit protection function

Technical Data

Model		ATO-NB8-631PC06
Rated Current		6A
Rated Voltage		230/400V
Frequency		50Hz
Number of Poles		1P
Mechanical Life		20000 Times
Electrical Life		10000 Times
Rated Short-Circuit Breaking Capacity		6000A
Operating Short-Circuit Breaking Capacity		6000A
Rated Impulse Withstand Voltage (1.2/50)		6kV
Dielectric Test Voltage		2000V (50Hz, 1 min)
Heat & Humidity Resistance		28 Cycles
Vibration Resistance		No Obvious Vibration and Impact
Terminal Block	Terminal Block Type	Pillar Terminal Block
	Min. Terminal Size Acceptability	1mm²
	Max. Terminal Size Acceptability	25mm²
	Standard Connection Torque	2 N.m
	Max. Tolerable Torque	2.5 N.m
	Wire Insertion Depth	13mm
Reference Temperature		30℃
Operating Temperature		-35℃~+70℃
Storage Temperature		35℃~+85℃
Applicable Altitude		2000m
Tripping Mode		Thermal Magnetic Trip
Electromagnetic Tripping Type		Type C (5In-10In)
Shell Flame Retardant Grade		V0
Wire Entry Method		Both Upper and Lower
Installation Method		TH35-7.5 Standard Rail
Protection Level	Direct Installation	IP20B
	Installed in the Distribution Box	IP40B

Single Pole MCB Breaker Dimension (Unit: mm)

6 amp 1 pole Miniature Circuit Breaker Dimensions

Details

Tips: The ultimate short-circuit breaking capacity and operating short-circuit breaking capacity of miniature circuit breakers

Ultimate short-circuit breaking capacity (I_cu): According to the conditions specified in the prescribed test procedures, excluding the breaking capacity of the circuit breaker to continue to carry its rated current capacity, in plain language, it means that this circuit breaker has a short-circuit fault when in use The expected maximum short-circuit current can be interrupted at a time without causing damage to the line, and the line is protected, but the micro-break is damaged or burned out and can no longer be used.
Operating short-circuit breaking capacity (I_cs): According to the conditions specified in the prescribed test procedures, including the breaking capacity of the circuit breaker to continue to carry its rated current capacity, in plain language, it means that when the circuit breaker is in use, the line has a short circuit fault It can break not more than a certain proportion of the expected maximum short-circuit current at a time without causing damage to the line. The line is protected, and the circuit breaker it self can still be used without damage.

Types of Circuit Breakers

In this video, we'll take a closer look at the meaning behind these abbreviations and explain the types of circuit breakers they represent. By understanding the different types of circuit breakers on the market, you can make an informed decision and choose the right type for your specific requirements, thereby enhancing the protection of your electrical infrastructure.

Isolator vs Circuit Breaker

Although isolators and circuit breakers have similar functions in a circuit, they are two separate entities. This video explains you the difference between the two devices in terms of working, features, operation, affordability, etc. You can choose between them based on your specific requirements.

Essential Electronic Components in Electrical Systems

Welcome back to the ATO Channel, you go-to source for electrical and industrial automation insights.

Relays vs Circuit Breakers: What’s the Difference

In this video, we've described the difference between a relay and a circuit breaker as well as explaining their basic working and operation by means of animation. If you find this video helpful, please LIKE it and SHARE with your friends. Don't forget to check out the purchase links above if any featured items're of your interest.
