    AC Gear Motors

    View as Grid List
    Display per page
    Sort by

    100W 3-Phase AC Gear Motor, Horizontal, Ratio 3~100

    $462.62
    SKU: ATO-GEAR-HV100
    Cheap AC gear motor for sale. Rated power 100W, optional power supply 110V/220V/380V (3-phase or single phase), gear ratio 3:1 to 100:1 for selection, output torque 0.16-5.8 kg.m, output shaft diameter 18mm/22mm, installation direction horizontal or vertical. Adding brake for power cutting is available.

    200W 3-Phase AC Gear Motor, Horizontal, Ratio 3~100

    $505.69
    SKU: ATO-GEAR-HV200
    Buy 3-phase AC gear motor at good price. Rated power 200W, power supply 110V/220V/380V at 3-phase or single phase, optional gear ratio 3:1~100:1, output torque 0.31-11.5 kg.m, output shaft diameter 18mm/22mm/28mm, horizontal/vertical installation. Matched with brake to control speed better.

    1/2 hp (400W) 3-Phase AC Gear Motor, Ratio 3~100

    $568.15
    SKU: ATO-GEAR-HV400
    Low rpm 3-phase AC gear motor has 0.5 hp (400W) working power, combined with an optional 90V brake for power cutting, gear ratio range from 3:1~100:1, torque 0.6~23 kg.m, rated voltage 110V/220V/380V, supporting horizontal and vertical installation, low price.

    1 hp (750W) 3-Phase AC Gear Motor, Ratio 3~100

    $811.69
    SKU: ATO-GEAR-HV750
    Good price 3-phase AC gear motor works at 1 hp rated power, gear ratio 3:1~100:1 for selection, torque 1.1~43.2 kg.m, shaft diameter 28mm/32mm, power supply 1-phase/3-phase 110V/220V/380V, horizontal/vertical installation. 750W electric gear motor can operated with a 90V brake to control power cutting.

    2 hp (1.5kW) 3-Phase AC Gear Motor, Vertical, Ratio 3~100

    $1,252.31
    SKU: ATO-GEAR-HV1500
    Affordable price 3-phase AC gear motor for sale, working power 2 hp (1.5kW), input voltage 110V/220V/380V (3-phase or single phase), optional gear ratio 3:1~100:1, torque 2.2~83.7 kg.m, shaft diameter 32mm/40mm, vertical/horizontal mounting type. Adding brake for electric geared motor power cutting is available.

    3 hp (2.2kW) 3-Phase AC Gear Motor, Vertical, Ratio 3~100

    $1,678.31
    SKU: ATO-GEAR-HV2200
    High torque AC gear motor with competitive price, operated by 3-phase 220V/380V power supply, input power 3 hp (2.2kW), gear ratio range from 3:1~100:1 for selection, torque 3.2~126 kg.m, supports vertical or horizontal installation. For power cut engine conveniently, a brake is recommended to match with AC geared motor.

    5 hp (3.7kW) 3-Phase AC Gear Motor, Vertical, Ratio 3~60

    $2,262.23
    SKU: ATO-GEAR-HV3700
    Buy 5 hp (3.7kW) AC gear motor at ideal price, input voltage 3-phase 220V/380V, gear ratio range 3:1 to 60:1 for selection, high torque 5.5~127 kg.m, low speed 570~25 rpm, shaft diameter 40mm/50mm, vertical/horizontal mounting. Optional matched brake is provided.

    3 W AC Gear Motor, Torque Motor with Gearbox, single phase

    $128.41
    SKU: ATO-GEAR-TM3
    3 W single phase gear motor, pinion shaft torque motor with gearbox, 50 Hz or 60 Hz frequency, 110V/ 220V AC voltage. Due to its high starting torque and sloping characteristics, it can adjust the torque and speed by changing the voltage applied to the motor.

    6 W AC Gear Motor, Torque Motor with Gearbox, single phase

    $154.68
    SKU: ATO-GEAR-TM6
    The provided torque motor is 6 W AC gear motor with gearbox, works at single phase 110V/220V voltage. It has high starting torque and sloping characteristics, allowing easily adjust the torque by changing the voltage going to the motor.

    10 W AC Gear Motor, Torque Motor with Gearbox, single phase

    $156.99
    SKU: ATO-GEAR-TM10
    ATO single phase pinion shaft torque motor, AC gear motor with gearbox, is extremely compact size, provides high starting torque, max. output power up to 10 W. With continuous torque ratings ranging from 25 Nm to 265 Nm, suitable for winding applications.

    20 W AC Gear Motor, Torque Motor with Gearbox, single phase

    $233.69
    SKU: ATO-GEAR-TM20
    Lower cost AC gear motor & torque motor with gearbox, 3, 5, 6...200 21 different kinds of gear ratio for you to choose. It has 20 W power and 1350 rpm rated speed, works at 110V/ 220V AC single phase voltage. The torque and speed can be adjusted by changing the voltage of the motor because of the large starting torque.

    25W Single Phase AC Gear Motor, Speed Control

    $264.36
    SKU: ATO-GEAR-5IK25W
    Single phase 25W AC gear motor is a speed control electric motor, which designed to produce high torque. Pinion shaft type or round shaft type for optional, different gear ratio to choose, the smaller reduction ratio, the higher gearbox output speed. The speed of the motor can be adjusted using the speed controller.

    40W Single Phase AC Gear Motor, Speed Control

    $305.79
    SKU: ATO-GEAR-5IK40W
    High torque single phase AC gear motor is 40W output power, combined with an easy to use speed controller, speed control range from 90-1650r/min, supporting clockwise and counterclockwise rotation, high velocity and energy saving.

    60W Single Phase AC Gear Motor, Speed Control

    $328.63
    SKU: ATO-GEAR-5IK60W
    Low RPM 60W AC motor adds mechanical gearbox to change the speed and torque of the motor for a particular application. Single phase 100V-230V rated voltage, 90-1650r/min speed control range, high velocity and energy saving. The speed and rotation direction of the motor can be adjusted using the speed controller.

    90W Single Phase AC Gear Motor, Speed Control

    $398.15
    SKU: ATO-GEAR-5IK90W
    High torque low rpm AC geared speed control motor for sales, output power is 90W, single phase 110V-230V, combined with an easy to use speed controller, small vibration and low noise, adopts pure copper coil for smooth running and long service life.

    120W Single Phase AC Gear Motor, Speed Control

    $420.16
    SKU: ATO-GEAR-5IK120W
    120 watt 90mm speed control AC gear motor is a specific type of electrical motor that is designed to produce high torque, available in single phase 100V-230V 50Hz/60Hz, speed control range from 90-1650r/min, supplied as lead wire only.

    140W Single Phase AC Gear Motor, Speed Control

    $475.39
    SKU: ATO-GEAR-6IK140W
    Single phase 140W 104mm AC gear motor with speed controller, easy to operate. It has a 90-1650 RPM motor output speed from the speed control module, superior performance and durable, supporting clockwise and counterclockwise rotation.

    200W Single Phase AC Gear Motor, Speed Control

    $538.41
    SKU: ATO-GEAR-6IK200W
    200 watt AC power single phase gear motor with high quality and competitive price, speed control range of 90-1350 rpm/min at 50Hz, 90-1650 rpm/min at 60Hz. This speed control motor can adjust motor speed easily when it connects with a speed controller.

    AC gear motor is an electrical motor that integrates a gearbox with an AC electric motor to deliver high torque at low speed or low horsepower. ATO offers 3 types of AC gear motors, which are 3 phase AC gear motor from 100W to 3.7kW power with horizontal or vertical installation, 110 V /220V single phase torque motor with gearbox, 25W to 200W single phase AC gear motor with speed control. The power supply frequency of our gear motors varies from region to region. In the case of automated equipment used in different regions, change the gear ratio of the gearhead or take the appropriate measure to obtain the desired speed. View the models in the AC gear motor list below, you can get a perfect solution with a reasonable price for your applications.

    AC gear motor vs. DC gear motor



    The gear motor is equipped with a reduction gearbox at the output end of the motor. AC gear motor and DC gear motor are two kinds of gear motors divided by working power. AC gear motor means that the power supply used is AC, such as 110 V, 120 V, 220 V and 240 v. DC gear motor adopts DC power supply as power supply, such as 12V, 24V and 48V.

    A gear motor is a reduction gearbox on the basis of an ordinary motor. The function of the reduction gearbox is to provide lower speed and higher torque. In addition, different reduction ratios of the transmission can provide different speeds and torques. The higher the transmission ratio, the lower the speed and the greater the torque. For example, there is an AC gear motor. When its gear ratio is 50:1, the speed is 30 revolutions, when its gear ratio is 25:1, the speed is 60 revolutions, and when its gear ratio is 15:1, the speed can reach 100 revolutions.

    3-Phase AC gear motor applications



    AC gear motor refers to the combination of a gearbox and a motor, which is also known as a gearbox motor or reduction motor. 3-Phase AC gear motor is widely used and belongs to the indispensable power transmission equipment of automatic machinery and equipment, especially in the fields of the smart home kitchen, medical equipment, industrial equipment, security equipment, office supplies, robots, and model airplanes.

    3-Phase AC gear motor in a smart home kitchen

    Mainly include household juicer motor, coffee machine motor, sweeper motor, etc. 3-Phase AC gear motor is manufactured in accordance with international professional standard production technology requirements. The low-noise technology allows users to not have to endure the trouble of noise when using it.

    Thress Phase AC gear motor in medical equipment

    Mainly include the research and development of medical equipment projects such as intelligent navigation electric wheelchair motors, minimally invasive abdominal surgery robot motors, intelligent massage chair motors, and medical robot motors. The 3-Phase AC gear motor has undergone precision machining to ensure positioning accuracy, forming mechatronics, which fully guarantees the quality of the product.

    3-Phase AC gear motor in industrial equipment

    Mainly include elevator motors, knife sharpener motors, blower motors, oven motors, etc. 3-Phase AC gear motor uses a serialized and modular design concept and has a wide range of adaptability. ATO 3-Phase AC gear motor has many combination installations, installation positions and structural solutions. Any speed and structure can be selected according to actual needs
