10μF 25V Aluminum Electrolytic Capacitor

5 out of 5 based on 1 reviews | Write a review

$1.06

High voltage aluminum electrolytic capacitor with 10μF capacity, 25 volt rated current, cap. tolerance is ±20%, direct plug installation type, 12% dissipation factor. 10uf 25v electrolytic capacitor is widely used in automotive, smart home, medical, industrial control and new energy industries.

SKU: ATO-EC-KF100M

This product has a minimum quantity of 100

Qty:

30-day Returns

Free Shipping

Delivery date: 6-12 days

Overview

Cheap price aluminum capacitor with size 5*11 mm, operating tempertaure -40~105℃, 1000 hours shelf life. The power capacitor has advantages of high reliability, small size and long service life.

Features

Endurance: 105℃- 2000 hours up to 5000 hours
Low impedance and high ripple current
High reliability
Wide voltage range

Specification

Model		ATO-EC-KF100M
Series		Low impedance 105°C type
Capacity		10 ㎌
Rated voltage		25V
Installation Type		Direct plug
Size		5*11 mm
Operating temperature		-40~105℃
Cap. tolerance (∆C)		±20% (120Hz 20℃)
Dissipation factor (tanδ)		12%
Low temperature characteristic at 120Hz (Z ratio max.)		3 (Z-25℃/ Z+20℃)
Leakage current (L_leak)		≤0.01CRV_Ror 3 ㎂ * after 2 minutes
Enduarance (105℃)	Test	2000h
	∆C	≤20% of initial measured value
	tanδ	≤200% of specified measured value
	L_leak	≤ the specified measured value
Shelf life (105℃)	Test	1000h
	∆C	≤20% of initial measured value
	tanδ	≤200% of specified measured value
	L_leak	≤ the specified measured value

Dimension (mm)

Electrolytic capacitor dimension

Model	Dimension (mm)
ATO-EC-KF100M	∅D	5
	F	2
	∅d	0.5
	a	1.5

Tips: How to Install Aluminum Electrolytic Capacitor?

Used capacitors are not reusable，except in the case that the capacitors are detached from a device for periodic inspection to measure theirelectrical characteristics.
lf the capacitors have self-charged, discharge the capacitors through aresistor of approximately 1kQ before use.
lf capacitors are stored at a temperature of 35°C or more and more than 75% RH,the leakage current may increase. lIn this case，they can be re-formed by applying the rated voltage through a resistor of approximately 1kQ.
