    100μF 450V Aluminum Electrolytic Capacitor

    Competitive price 100μF electrolytic capacitor for sale. Aluminum electrolytic capacitor rated voltage 450V, cap. tolerance ±20%, direct plug installation type. Aluminum capacitors in electronic circuits is to pass alternating current and block direct current. High voltage 450V electrolytic capacitors are used in various electronic products with compact structure, small volume and high precision.
    SKU: ATO-EC-KF101M450K
    This product has a minimum quantity of 100
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    High quality power capacitor with dissipation factor 17%, 100μF capacity, 450V rated voltage,  operating tempertaure -40~105℃.


    • Endurance: 105℃- 2000 hours up to 5000 hours
    • Low impedance and high ripple current
    • High reliability
    • Wide voltage range


    Model ATO-EC-KF KF101M450K
    Series Low impedance 105°C type
    Capacity 100 μF
    Rated voltage 450V
    Installation Type Direct plug
    Size 18*35.5 mm
    Operating temperature -40~105℃
    Cap. tolerance (C) ±20% (120Hz 20℃)
    Dissipation factor (tanδ) 17%
    Low temperature characteristic at 120Hz (Z ratio max.) 6 (Z-25℃/ Z+20℃)
    Leakage current (Lleak) 0.01*CR*Vor 3  * after 2 minutes
    Enduarance (105℃) Test 2000h
    ∆C 20% of initial measured value
    tanδ ≤200% of specified measured value
    Lleak ≤ the specified measured value
    Shelf life (105℃) Test 1000h
    ∆C 20% of initial measured value
    tanδ ≤200% of specified measured value
    Lleak ≤ the specified measured value

    Dimension (mm)

    Electrolytic capacitor dimension

    Model Dimension (mm)
     ATO-EC- KF101M450K D 18
    F 7.5
    ∅d 0.8
    a 1.5

    Tips: What is Aluminum Electrolytic Capacitor?

    Aluminum electrolytic capacitors are made of an aluminum cylinder as the negative electrode, which is filled with liquid electrolyte and inserted into a bent aluminum strip as the positive electrode. It also needs to be treated with DC voltage to form an oxide film on the positive plate as a medium. It is characterized by large capacity, but large leakage, poor stability, positive and negative polarity, and is suitable for power supply filtering or low-frequency circuits. When using, do not reverse the positive and negative poles.
