    220μF 35V Aluminum Electrolytic Capacitor

    220μF 35V electrolytic capacitor for sale at reasonable price. High voltage electrolytic capacitor with cap. tolerance is ±20%, direct plug installation type, 10% dissipation factor. The power capacitor has advantages of high reliability, high ripple current, small size and long service life.
    SKU: ATO-EC-KF221M
    This product has a minimum quantity of 100
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Cheap price aluminum capacitor with operating tempertaure -40~105℃, 5000 hours endurance. Aluminum electrolytic capacitor is widely used in automotive, smart home, medical, industrial control and new energy industries.


    • Endurance: 105℃- 2000 hours up to 5000 hours
    • Low impedance and high ripple current
    • High reliability
    • Wide voltage range


    Model ATO-EC-KF221M
    Series Low impedance 105°C type
    Capacity 220
    Rated voltage 35V
    Installation Type Direct plug
    Size 8*11.5 mm
    lead spacing 3.5 mm
    Operating temperature -40~105℃
    Cap. tolerance (C) ±20% (120Hz 20℃)
    Dissipation factor (tanδ) 10%
    Low temperature characteristic at 120Hz (Z ratio max.) 3 (Z-25℃/ Z+20℃)
    Leakage current (Lleak) 0.01*CR*Vor 3  * after 2 minutes
    Enduarance (105℃) Test 5000h
    ∆C 20% of initial measured value
    tanδ ≤200% of specified measured value
    Lleak ≤ the specified measured value
    Shelf life (105℃) Test 1000h
    ∆C 20% of initial measured value
    tanδ ≤200% of specified measured value
    Lleak ≤ the specified measured value

    Dimension (mm)

    Electrolytic capacitor dimension

    Model Dimension (mm)
     ATO-EC- KF221M D 10
    F 5
    ∅d 0.6
    a 1.5

    Tips: How to Install Aluminum Electrolytic Capacitor?

    1. Verify the polarity of the capacitors.
    2. Do not use the capacitors if they have been dropped on the floor.
    3. Do not deform the cases of capacitors.
    4. Verify that the lead spacing of the capacitor fits the hole spacing in the PC board before installing the capacitors. Some standard pre-formed leads are available.
