    10μF 400V Aluminum Electrolytic Capacitor

    5 out of 5 based on 1 reviews | Write a review
    High voltage 400V electrolytic capacitor at lower cost. Aluminum electrolytic capacitor with 10μF capacity, cap. tolerance ±20%, direct plug installation type. 10μF electrolytic capacitors can be applied for air conditioners, tape recorders, washing machines, communication machines and other household appliances.
    SKU: ATO-EC-KF100M400G
    This product has a minimum quantity of 100
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    High quality power capacitor with 10μF capacity, 400V rated voltage, dissipation factor 15%, Z-Max.lmpedance 1100mΩ, operating tempertaure -40~105℃. The electrolytic capacitor providing good electrical performance, wide application range and high reliability.


    • Endurance: 105℃- 2000 hours up to 5000 hours
    • Low impedance and high ripple current
    • High reliability
    • Wide voltage range


    Model ATO-EC-KF100M400G
    Series Low impedance 105°C type
    Capacity 10 μF
    Rated voltage 400V
    Installation Type Direct plug
    Size 10*12.5 mm
    Operating temperature -40~105℃
    Cap. tolerance (C) ±20% (120Hz 20℃)
    Dissipation factor (tanδ) 15%
    Low temperature characteristic at 120Hz (Z ratio max.) 5 (Z-25℃/ Z+20℃)
    Leakage current (Lleak) 0.01*CR*Vor 3  * after 2 minutes
    Enduarance (105℃) Test 2000h
    ∆C 20% of initial measured value
    tanδ ≤200% of specified measured value
    Lleak ≤ the specified measured value
    Shelf life (105℃) Test 1000h
    ∆C 20% of initial measured value
    tanδ ≤200% of specified measured value
    Lleak ≤ the specified measured value

    Dimension (mm)

    Electrolytic capacitor dimension

    Model Dimension (mm)
     ATO-EC-KF100M400G D 10
    F 5
    ∅d 0.6
    a 1.5

    Tips: Features of Aluminum Electrolytic Capacitor.

    1. The capacitance per unit volume is very large, tens to hundreds of times larger than other types of capacitors.
    2. The rated capacity can be very large, which can easily reach tens of thousands of μf or even a few f (but cannot be compared with the electric double layer capacitance).
    3. The price has an overwhelming advantage over other types, because the components of electrolytic capacitors are all common industrial materials, such as aluminum and so on. The equipment for manufacturing aluminum electrolytic capacitors are also common industrial equipment, which can be mass-produced and the cost is relatively low.
