    2A 120V 240W Variable Linear DC Power Supply

    240W power rating variable linear DC power supply with 3 digit LED display, designed to regulate adjustable 0 to 2A and 0 to 120V outputs. Features high accuracy, low ripple, low noise, this adjustable DC power supply can be used in dual input voltage 110V or 220V AC (+/- 10%). With digital control capabilities, it ensures precision and ease of operation.
    SKU: ATO-DCPS1202
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    2 amp 120 volt adjustable linear DC power supplies often incorporate digital control interfaces, facilitating precise adjustments with user-friendly interfaces. Users can effortlessly set desired voltage levels and control amperage with accuracy, granting flexibility in powering diverse circuits or components.


    Model ATO-JK1202D
    Input Voltage 110V or 220V AC (+/- 10%)
    Output Voltage Range DC 0-120V
    Output Current Range 0-2A
    Output Power 240W
    Frequency 50Hz/60Hz
    Output Type Dual
    Display 3 digit
    Display Accuracy ≤ ±0.1%+2d
    Voltage Display Resolution 10mV
    Current Display Resolution 10mA
    Efficiency >65%
    Voltage Regulation
    Load Regulation (CV) 1×10-1+8mV
    Line Regulation (CV) 1×10-1+3mV
    Ripple & Noise (P-P) 0.5mV
    Temperature Coefficient 300PPm/℃
    Current Regulation
    Load Regulation (CC) ≤5mA
    Line Regulation (CC) 2×10-1+3mA
    Temperature Coefficient 500PPm/℃
    Protection Over Load and Over Voltage Protection
    Recovery Time ≤100µs
    Operating Ambient 0℃ to + 40℃/ 85%RH
    Storage Ambient -10℃ to + 80℃/ 80%RH
    Warranty 12 Months
    Size 290 (L) x 130 (W) x 165 (H) mm
    Weight 6.5kg


    2A 120V variable linear DC power supply detail

    Tips: Can I use a variable linear DC power supply for electroplating applications?

    Using a variable linear DC power supply for electroplating applications is feasible, but it has limitations. Electroplating typically requires a stable and controlled DC voltage to ensure consistent deposition of metal ions onto the substrate. While a linear power supply can provide a steady output, it may face challenges in terms of precision and efficiency compared to specialized electroplating power sources. Electroplating often demands specific current and voltage profiles for different stages of the process, which might be better addressed by dedicated electroplating power supplies designed to handle the dynamic requirements of the application. Additionally, linear power supplies may generate more heat and be less energy-efficient compared to other options. Consider consulting with experts and ensuring that the power supply can meet the specific demands of your electroplating process before use.
