    Laser Belt Tension Meter

    Cost-effective laser belt tension meter uses a laser sensor for direct measurement, which with a 10-500Hz measuring range, and a sensor depth of about 66mm. High-performance belt tension meter is suitable for measurement in small spaces.
    SKU: ATO-TM500
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Reliable laser belt tension meter with ±5% accuracy, max frequency 500Hz. The belt tension meter can measure the natural vibration frequency of the belt through the emission and reception of the laser, and then calculate the tension value of the belt by combining the input belt mass and the free belt length.


    Model ATO-BTT2880R5
    Measuring Range 10-500 Hz
    Input Range Max. 99.9 m
    Belt Quality Max. 999.9 g/m
    Digital Sampling Error <1%
    Display Error ±1 Hz
    Total Error <5%
    Operating Temperature 10℃~50℃
    Transport Temperature -5℃~70℃
    Display LCD
    Units of Measurement m, kg/m, N
    Power Supply 4*1.5V AAA
    Optical Path Measurement Distance 3-20mm
    Sensor Depth about 66mm
    Meter Size

    Host: 178*72*34mm

    Sensor: 124*21*12mm


    Tension meters are instruments that measure tension in cable, fiber, belts and webs, or sheets. ATO tension meter mainly used in belt tension measurement can also be applied to measure the tension of objects such as tapes, and wires. Widely applied in industries of automobile, textile, cables, wires, plastic films, paper, and printing.

    Tension meter application

    Tips: Precautions when using the belt tension meter

    1. The calibration of belt tension meter must be calibrated according to the standard method, otherwise, it will cause the measurement error in the instrument. Keep in mind that the measuring head must be removed from the belt when zeroing, and the jaw knob must be completely loosened. Moreover, the belt tension meter should be calibrated regularly.
    2. If the belt tension meter will not be used for a long time, it is best to take out the battery to prevent the battery from rotting or leaking and causing damage to the instrument.
    3. The belt tension gauges of different measuring heads will be different with the rotation of the engine, which is caused by different internal loads on the crankshaft during rotation.
    4. Keep in mind that the measuring head must be removed before rotating the machine shaft. If a long-term measurement is performed, it is best to calibrate a zero every 10 minutes.
