    Sonic Tension Meter, 10-680 Hz

    Good price high quality sonic tension meter is a instruments for measuring belt tension, which with a 10-680 Hz measuring range, can store 20 sets of belt parameters, and the probe can be adjustable. The belt tension meter is an optically measuring maintenance tool for determining the belt tension force, a small impulse on the belt is sufficient to set the belt vibrating.
    SKU: ATO-TM680
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Sonic belt tension meter with ±5% accuracy, max frequency 680Hz. The sonic belt tension meter can be used to measure the vibration frequency of the transmission belt when it is hit or moving fast.


    Model ATO-BTT2880S
    Measuring Range 10-680 Hz
    Free Segment Belt Length Max. 999.9 mm
    Belt Width Max. 999.9 mm/ R
    Belt Quality Max. 999.9 g/m
    Precision ±1 Hz<100Hz, ±1%>100Hz
    Digital Sampling Error <1%
    Display Error ±1 Hz
    Total Error <5%
    Operating Temperature 10℃~50℃
    Transport Temperature -5℃~70℃
    Display LCD
    Units of Measurement Hz/N
    Power Supply 4*1.5V AAA
    Shell ABS
    Meter Size 140*72*34mm


    Tension meters are instruments that measure tension in cable, fiber, belts and webs, or sheets. ATO tension meter mainly used in belt tension measurement can also be applied to measure the tension of objects such as tapes, and wires. Widely applied in industries of automobile, textile, cables, wires, plastic films, paper, and printing.

    Tension meter application

    Tips: What does a sonic tension meter do?

    Applicable to a V-belt, a V-ribbed belt or a synchronous belt, the device analyses sound waves from the belt through the sensor and delivers an accurate tension measurement without delay. This is essential for the optimum performance and reliability of your belt drives.
