    1/2" Brass Ball Valve with Handwheel

    5 out of 5 based on 1 reviews | Write a review
    Factory price 1/2 inch brass ball valve with handwheel for sale, DN15, 1.6MPa, double acting. This fixed forged brass ball valve can be used to control water, oil, non-corrosive and non-combustible gas, etc.
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Low cost threaded brass ball valve with handwheel is used for water and flow control. This manual ball valve has good sealing performance and a good flow adjustment function.


    • Model: ATO-BBVH-DN15
    • Nominal Diameter: DN15
    • Nominal Pressure: 1.6MPa
    • Size: 1/2 inch
    • Body Material: Brass
    • Connection Type: Thread
    • Standard: Compliant with ISO 228 Standard
    • Structure: Fixed Ball Valve
    • Applicable Temperature: -10℃≤T≤120℃
    • Valve Action: Flow Control
    • Mode of Action: Double Acting
    • Channel Location: Straight
    • Sealing Material: Rubber
    • Sealing Method: Soft Seal
    • Drive Mode: Handwheel
    • Flow Direction: Bidirectional
    • Working Medium: Water, Oil, Non-Corrosive and Non-Combustible Gas
    • Weight: 230g

    Dimensions & Details (Unit: mm)

    Dimensions of brass ball valve with handwheel

    DN Size A B C H L
    15 1/2 55 12.5 14 70 42
    Number 1 2 3 4 5 6 7 8 9 10 11
    Component Valve Body Valve Plate Valve Stem Gasket Valve Cap Locking Cap Filler Pressure Cap Handwheel Brand Hex Nut
    Material Brass Brass Brass PTFE Brass Brass PTFE Brass Iron Aluminum Stainless Steel

    Tips: What are the advantages of brass ball valve?

    • Easy to install: if the switch is screwed into position, it can be locked. Usually, straight pipe sections need to be cut when connecting to pipes.
    • All-round leak-proof design (welding type), and the O-ring with special structural design ensures reliable sealing without leakage points at different positions.
    • Manual device: If you want to change the direction in the closed state, you only need to pull the handwheel and it can be done easily.
