10A 12V 120W Variable Linear DC Power Supply

$291.49
Purchase high efficiency 0 to 10A, 0 to 12V variable linear DC power supply online at a favorable price. This is a switching mode with 120W DC output. Output voltage and current are continuously adjustable at nominal value, with constant voltage (CV) / constant current (CC) output precision. This adjustable and regulated linear DC power provides a stable power source for diverse applications.
*
SKU: ATO-DCPS1210
30-day Returns
Free Shipping
Delivery date: 6-12 days

12 volt 10 amp variable linear DC power supply caters to a diverse array of applications in electronics, prototyping, and testing. Its linear configuration plays a pivotal role in minimizing output noise, thereby augmenting the stability of interconnected circuits. This adjustable linear DC power supply offers precise adjustments for voltage and amperage settings, ensuring optimal performance and safety for connected devices.

Specification

Model ATO-JK1210S
Input Voltage 110V or 220V AC (+/- 10%)
Output Voltage Range DC 0-12V
Output Current Range 0-10A
Output Power 120W
Frequency 50Hz/60Hz
Output Type Dual
Display 3 digit
Display Accuracy ≤ ±0.1%+2d
Voltage Display Resolution 100mV
Current Display Resolution 100mA
Efficiency >65%
Voltage Regulation
Load Regulation (CV) 1×10-5+2mV
Line Regulation (CV) 1×10-5+5mV
Ripple & Noise (P-P) 0.5mV
Temperature Coefficient 300PPm/℃
Current Regulation
Load Regulation (CC) 5×10-5+10mV
Line Regulation (CC) 3×10-5+10mA
Temperature Coefficient 300PPm/℃
Others
Protection Over Load and Over Voltage Protection
Recovery Time ≤100µs
Operating Ambient -10℃ to + 45℃/ 85%RH
Storage Ambient -10℃ to + 80℃/ 80%RH
Warranty 12 Months
Size 290 (L) x 130 (W) x 165 (H) mm
Weight 5.5kg


Detail

10A 12V variable linear DC power supply detail

Tips: How do I calibrate a variable linear DC power supply?

To calibrate a variable linear DC power supply, follow these steps. First, ensure the power supply is off. Connect a calibrated voltmeter to the output terminals. Set the power supply to a specific voltage and turn it on. Adjust the output voltage knob until the voltmeter reads the desired value. Repeat this process for multiple voltage settings across the range. Check the accuracy at various points to identify any discrepancies. If necessary, make adjustments using the calibration controls provided by the manufacturer. Confirm the accuracy again after adjustments. Additionally, consider calibrating the current limiting function by using a calibrated ammeter and a load resistor. Document the calibration results and keep a record for future reference. Periodic recalibration is recommended to maintain accuracy.
