12V DC 25A 300W Switching Power Supply

5 out of 5 based on 2 reviews | Write a review
$77.34
Low price 300W switching power supply converts universal AC to 12V DC at rated current of 25A. Quality SMPS power supply has built-in DC fan for cooling and short circuit, overload and overvoltage protections, ideal for all kinds of electrical equipment or devices.
SKU: ATO-SMPS-300-12
30-day Returns
Free Shipping
Delivery date: 6-12 days

Features

  • Univeral AC input/Full range
  • Protections: short circuit, overload and overvoltage
  • Forced air cooling by built-in DC fan
  • PWM control and regulated
  • 100% full load burn-in test
  • Low cost, compact size and high efficiency

Specification

Model ATO-S-300-12
Output
DC Voltage 12V
Rated Current 25A
Current Range 0 ~ 25A
Rated Power 300W
Ripple & Noise (Max.)(Note 2) 150mVp-p
Voltage Adjust Range 10 ~ 13.2V
Voltage Tolerance (Note 3) ±1.0%
Line Regulation ±0.5%
Load Regulation ±0.5%
Setup, Rise, Holdup Time 200ms, 50ms, 20ms at full load
Input Voltage Range 90 ~ 132VAC/180V~264VAC (selected by a switch) or 254 ~ 370VDC
Frequency Range 47~63Hz
Efficiency (Typ.) 74%
AC Current (Typ.) 6.5A/115V AC 4A/230V AC
Inrush Current (Typ.) Cold start: 50A/230V AC
Leakage Current <3.5mA/240V AC
Protection Overload 105~135% rated output power
Protection type: Constant current limiting, recovers automatically after fault condition is removed.
Overvoltage 13.8~16.2V
Protection type: Hiccup mode, recovers automatically after fault condition is removed.
 Over temperature RTH3 ≥65°C FAN ON, ≤55°C FAN OFF, ≥80°C output shut down.
Environment Working Temperature -10 ~ +50℃
Working Humidity 20~90% RH non-condensing
Storage Temperature -20~+85℃
Storage Humidity 10~95% RH non-condensing
Temperature Coefficient ±0.03%/℃ (0~50℃)
Vibration 10 ~ 500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes
Safety & EMC Withstand Voltage I/P-O/P: 1.5KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC
Isolation Resistance I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC/25℃/70% RH
Others MTBF ≥234.3K hrs MIN. MIL-HDBK-217F (25℃)
Dimension 215*115*50mm (L*W*H)
Weight 1.1kg
Note 1. All parameters NOT specially mentioned are measured at 230V AC input, rated load and 25°C of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance includes set up tolerance, line regulation and load regulation.

Dimension (Unit: mm)

300W switched mode power supply dimensionSMPS power supply terminal pin number assignment

Details

12V DC Switching Power Supply Details

SMPS Power Supply Applications

  • Power Tools
    Electric Saw, Drilling Machine, Ginder, Sand Blast Machine, Puching Machine, Weeding Machine, Air Compressor, etc.
  • Offices Devices
    Computer, Printer, LCD Monitor, Scanning Machine, etc.
  • Electrics & Household Appliance
    TV, VCRS, Radio, Dust Collector, Fan Lamp or LED Strip, Sewing Machine, Microwave Oven, Fridge/Freezr, Coffemarker, etc.
  • Industrial Equipemnt
    Monitoring Equipment, Shipping, Vehicle, Metalhalide Lamp, Solar System, Wind Power Generation, etc.

Tips: Advantages and disadvantages of switching power supply

♦ SMPS advantages

1. Switching power supply is characterized by low energy consumption and high efficiency. In circuits of switching power supply, transistors excited by drive signals operates in alternating status from “on” to “off” or from “off” to “on”. Fast conversion speed and low energy consumption of switching transistors have greatly improved efficiency of power supply.

2. SMPS power supply is characterized by small size and weight. The switching power supply is equipped with no transformer and cooling fins, so it presents smaller size and weight.

3. Switching power supply excels in its regulation range. Input voltage of the SMPS is adjusted by occupation ratio of drive signals. Changes of input signal voltage can be compensated by frequency modulation or width adjustment. When industrial frequency power grid experiences great changes, the switching power supply can still maintain stable output of voltage.

♦ SMPS disadvantages

1. Switching power supply keeps bothered with serious switching noises. In the switching power supply, power switches and transistors remain in working status. AC voltage and AC current generated by them exerts pulse noises and resonance noises on other components. If users fail to inhibit, eliminate or shield these noises, the operation of the equipment will be seriously influenced.

2. SMPS power supply provides no isolation for transformer of industrial frequency. Therefore, the noise may be passed to power grid of industrial frequency, sending serious noise to connected electronic devices, equipment and household appliances. Switching power supply performs poorly in coping with electromagnetic noise, but modern shield technologies can compensate its disadvantage in this aspect.
