    3 Ton Electric Beam Trolley

    Beam trolley for electric chain hoist comes with 3 ton load capacity, running speed 11~21 m/min, motor voltage 380V or 110V, motor power 0.75 KW, min. turning radius 1.6, applicable I-beams 100~180mm. This electric beam trolley consists of a motorized unit equipped with wheels that travel along the beam, allowing for smooth and controlled horizontal motion.
    30-day Returns
    Free Shipping
    Delivery date: 10-12 days

    3 ton electric beam trolleys find extensive applications in warehouses, manufacturing plants, construction sites, and other environments where lifting and transferring heavy loads are required. They enhance productivity, reduce manual labor, and provide a cost-effective solution for material handling operations.


    • Model: ATO-HX-03
    • Load Capacity: 3 Ton
    • Running Speed: 11~21 m/min
    • Motor Voltage: 380V/ 110V
    • Motor Power: 0.75 KW
    • Minimum Turning Radius: 1.6
    • Applicable I-beams: 100~180mm


    Electric beam trolley dimensions

    A B R T
    340mm 250mm 142mm 231mm

    Tips: What is the use of beam trolley?

    A beam trolley is a mechanical device designed to move along a beam or track, typically used in industrial and commercial settings. It consists of a trolley frame with wheels or rollers that allow it to traverse horizontally along the length of a beam. The primary purpose of a beam trolley is to provide a means of transporting heavy loads across a defined path.

    Beam trolleys are commonly used in warehouses, manufacturing facilities, construction sites, and other environments where the movement of heavy materials or equipment is required. They are often used in conjunction with cranes or hoists to facilitate the lifting and transfer of loads. By attaching the load to the trolley, it can be easily moved along the beam, enabling efficient and controlled transportation.

    The versatility of beam trolleys allows them to be used in various applications. They are particularly useful for tasks such as loading and unloading trucks, transferring materials between different workstations, positioning equipment, and assembling large structures. Beam trolleys can be manually operated or powered, depending on the specific requirements of the operation.

    In summary, beam trolleys play a crucial role in streamlining material handling processes, improving efficiency, and enhancing workplace safety by enabling the smooth movement of heavy loads along beams or tracks.
