Digital Temperature Sensor with transmitter, Pt100, 2 Wire

5 out of 5 based on 2 reviews | Write a review

$173.85

RTD sensor with digital meter can directly display high-precision real-time temperature. It converts temperature to 4-20mA standard signal proportional to the electrical signals of thermistor, and outputs to display instrument or DCS system in control room. Built-in small transmitter adopts silicone rubber seal structure, good anti-interference ability, shock and humidity, apply to harsh environments. Measuring temperature range -200~+420 ℃.

SKU: ATO-RTD-D2W

Total Length of Thermowell *
Required Temperature for 4mA (℃) *
Required Temperature for 20mA (℃) *

Qty:

Free Shipping Worldwide

Delivery date: 6-12 days

Overview
Relative Video
Dimension

RTD temperature sensor can directly provide accurate input signal of temperature changes for display instruments, recording instruments, signal conditioners, scanister and computer.

Specification:

1. RTD temperature range and accuracy chart

Type of sensing element	Measuring range	Allowable deviation Δt
Pt100	-200~420℃	Class B (-200~800℃) Permissible deviation ±(0.30+0.005\|t\|)
Pt100	-200~420℃	Class A (-200~650℃) Permissible deviation ±(0.15+0.002\|t\|)
Cu50	-100~150℃	-50~100℃ Permissible deviation ±(0.30+6.0*10-3t)

Note: t is the actual measuring temperature absolute value of the temperature sensing element.
2. Transmitter parameter chart

Input	Platinum thermistor: PT100, PT1000
Output	4-20mA
Intrinsic error	±0.2%, ±0.5%
Transmission mode	Two wire
Supply voltage	DC 12~35V, rated voltage DC 24V
Load resistance	0~600Ω (DC 24V), rated load 250Ω
Temperature influence	≤0.05/1℃
Working environment	Temperature: -25~+80℃, humidity: 5%~95%, mechanical vibration: f≤55Hz, amplitude＜0.15mm
Display	3 1/2digital display or LCD display, temperature unit is degree centigrade (℃).

3. Meter and protection head type (unit: mm)
RTD sensor meter and protection head type

4. Selection chart

Type of sensing element	Meter type	Installing form	Mode of connection	Thermowell diameter	Thermowell total length
T4: Pt100; T6: Pt1000	P0: No meter; P2: Meter with digital display (unit: ℃); P4: Intelligent meter with digital display (unit: ℃)	I1: No fixed device; I2: Fixed card sets of thread joint (thread M272mm); I3: Movable card sets of thread joint (thread M272mm); I4: Fixed card sets of flange (flang DN 15mm); I6: Taper thermowell and fixing thread (thread M27*2mm)	C3: Standard waterproof protection head; C4: Explosion-proof protection head	D0: Φ16mm (when thermowell insertion depth≥300mm); D1: Φ12mm (when thermowell insertion depth＜300mm)	225~2150mm

Note: The sensing element is sheath RTD sensor, thermowell material is stainless steel, and circuit adopts non-isolated type. When ordering products, write the thermowell insertion depth l and the corresponding temperature range for output 4~20mA signal you need.
Tips: Troubleshooting of Pt100 RTD sensor

Fault: Instrument shows negative value.
Possible cause: Wrong connection between display instrument and Pt100 RTD sensor, or short circuit of Pt100 RTD sensor.
Processing method: Correct the connection, find out short circuit position and strengthen insulation.
Fault: Instrument shows that the indicated value of Pt100 RTD sensor is lower than the actual value or the indicating value is unstable.
Possible cause: There are metal chips, dust, dirt among wiring terminal and Pt100 RTD sensor short circuit.
Processing method: Remove metal chips, clean dust and water drops, find out short circuit position and strengthen insulation.
Fault: Instrument displays infinity.
Possible reasons: Pt100 RTD sensor or lead wire short circuit, or connection terminal loosening, etc.
Processing method: Change the resistance body, or welding and tighten the thread screw.
Fault: Relation between Pt100 RTD sensor resistance value and temperature has changed.
Possible cause: Resistance wire of Pt100 RTD sensor become corrosive and degenerative.
Processing method: Replace resistance wire of Pt100 RTD sensor.

In this video, ATO will show you how to use RTD PT100 with transmitter and temperature controller to measure temperature.

Fixed Installation Dimension Drawing

Design serial number		1
Structure diagram
Name		Fixed thread
Size		M272 (default), G3/4", M332, G1", other
Protection tube	Diameter	φ12mm, φ16mm, other
	Texture of material	1Cr18Ni9Ti, 2Cr25Ni20, other
	Withstand voltage	≤10MPa
Design serial number		2
Structure diagram
Name		Movable flange
Protection tube	Diameter	φ12mm, φ16mm, other
	Texture of material	1Cr18Ni9Ti, 2Cr25Ni20, other
	Withstand voltage	Atmospheric pressure
Design serial number		3
Structure diagram
Name		Fixed flange
Size		DN15mm (default)	D0	95mm	DN20mm	105mm
			D1	65mm		75mm
			D2	45mm		55mm
			φn	4-φ14mm		4-φ14mm
		DN25mm	D0	115mm	DN32mm	140mm
			D1	85mm		100mm
			D2	65mm		78mm
			φn	4-φ14mm		4-φ18mm
		DN40mm	D0	150mm	DN50mm	165mm
			D1	110mm		125mm
			D2	85mm		100mm
			φn	4-φ18mm		4-φ18mm
		H	12mm
Protection tube	Diameter	φ12mm, φ16mm, other
	Texture of material	1Cr18Ni9Ti, 2Cr25Ni20, other
	Withstand voltage	≤6.4MPa
Design serial number		4
Structure diagram
Name		Conical fixed thread
Size		M272 (default), M332, G1", other
Protection tube	Diameter	φ12mm, φ16mm, other
	Texture of material	1Cr18Ni9Ti, 2Cr25Ni20, other
	Withstand voltage	≥30MPa

Existing reviews of Digital Temperature Sensor with transmitter, Pt100, 2 Wire

Good 2-wire digital temperature sensor

Before shipping, can you send me some photos of this Pt100 digital temperature sensor?

From: Rural | Date: 02/03/2021

Was this review helpful? Yes No (0/0)

ATO Responded

We hope to get this order. Yes, we will fully support you. And will send you the photos of the Pt100 digital temperature sensor before shipment.

Can the digital temperature sensor be customized?

I'm looking a PT 100, class B, RTD sensor probe with protection head, about 60 inches long shealth, fixing thread, but wtihout thermowell, just sensor probe with head. Can you customize based on our specs?

From: Michelle | Date: 22/04/2021

Was this review helpful? Yes No (0/0)

ATO Responded

Yes, we can. Please inform about your specs (sheath length, diameter, 2 or 3 wires etc.), so can quote accordingly.
