    32 amp 3 pole Miniature Circuit Breaker

    5 out of 5 based on 2 reviews | Write a review
    32 amp 3 pole miniature circuit breaker at lower price, standard 35 mm DIN rail mounting, easy to install. It is capable of protecting the system against short circuit current up to 6kA, with C curve trip characteristic.
    SKU: ATO-MCB-3P32
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Circuit Breaker Information

    • Rated Current: 32 amp
    • Rated Voltage: 230/400V AC, 50Hz
    • Number of poles: 3 pole
    • 6 kA short circuit interrupting capacity
    • 35mm DIN rail mounted
    • Suitable for supplementary protection
    • With C curve trip characteristic

    Technical Data

    Model ATO-NB8-633PC32
    Electrical Parameters Height 86 mm
    Width 18 mm per pole
    Mounting DIN Rail
    Rated Current (In) 32A
    Number of poles 3P
    Rated Voltage (Ue) 230/400V
    Rated Insulation Voltage (Ui) 500V
    Dielectric Test Voltage 2000V
    Rated Frequency 50Hz
    Short Circuit Interrupting Capacity 6KA
    Trip Characteristic C Curve (5-10In)
    Rated Short-Circuit Breaking Capacity 6000A
    Operating Short-Circuit Breaking Capacity 6000A
    Mechanical Parameters Electrical Life 10000 times
    Mechanical Life 20000 times
    Flame Retardant Grade V0
    Protection Degree Direct installation: IP20B
    Installed in the distribution box: IP40B
    Calibration Temperature 30℃
    Operating Temperature -35℃~+70℃
    Storage Temperature -35℃~+85℃
    Tightening Torque 2 N.m
    Max. Tolerable Torque 2.5 N.m
    Terminal Size Acceptability–Min/Max 1 mm2 / 25mm2
    Wire Insertion Depth 13mm

    Circuit Breaker Dimension (Unit: mm)

    32 amp 3 pole Miniature Circuit Breaker Dimensions


    3 pole Miniature Circuit Breaker Details

    Tips: Measurements of molded case circuit breaker prevent the burning of brake windings

    1. Time delay normally open contact is changed to a pair of normally open contact. Auxiliary switch contact and auxiliary switch arm screw are often checked. The position of auxiliary switch is adjusted correctly to make sure that auxiliary switch and circuit breaker brake are put in the right position where they work efficiently.
    2. Coil of brake is well fixed and its iron core is often checked to make sure that it runs smoothly.
    3. The switch-on time generated by protection control device is capable of switching on the coil brake and quitting the switch-on order in a short time.
    4. In the annual maintenance work, the connecting rod mechanism of circuit breaker should be properly adjusted and the free tripper of circuit breaker is often checked to make sure it works well and it can be disconnected reliably in the rated low voltage between 30% and 65%.
