    370W AC Vibration Motor, 3 Phase, 4 Pole

    5 out of 5 based on 1 reviews | Write a review
    $921.87
    4 Pole industrial shaker motor, 3 phase, 1440 rpm, 220V AC voltafe, the vibration motor adopts high-quality bearings to ensure the smooth operation of the vibration motor, low noise, wear resistance and longer service life.
    SKU: ATO-AVM-MVE70015
    *
    Free Shipping Worldwide
    Delivery date: 6-12 days

    Waterproof three phase vibration motor, 370W power, 1.32A rated current, excellent sealing performance, IP65, anti-dust, and reliable operation of the motor.

    Specification

    Model ATO-MVE70015
    Phase 3 Phase
    Pole 4 Pole
    Force 693 Kg, 7 kN
    Speed 1440 rpm
    Power 370W (0.37kW)
    Current 1.32A
    Voltage Class 3 Phase 220V 50Hz/380V 50Hz
    Weight 28.0 kg
    Frame No. 50
    Frequency 50 Hz/60 Hz
    Protection Rank IP65
    Insulation Class F
    Certificate CE
    Warranty 12 Months

    370W 3 Phase Vibration Motor Dimension (unit: mm)

    370W 3 phase vibration motor dimension

    A B C D E F G H I L M N Cable Gland
    120 170 391 208 210 22 17 94 180 205 93 170 M20*1.5

    3 Phase 4 Pole AC Vibration Motor Structure
    3 Phase vibration motor structure

    Tips: How to choose vibration motor?

    Vibration motor as vibrating screen vibration source, should have reasonable design, simple structure, compact, high excitation efficiency, energy saving, convenient installation and debugging advantages, vibration motor selection, specific should choose the working frequency, maximum excitation force, power, etc.. The speed of the vibration motor should be close to the working frequency, and the maximum excitation force must be in the range of the selected motor synthesis excitation force, and then select the power of the vibration motor according to the selection of the working frequency and the maximum excitation force. ATO vibration motor waterproof and dustproof function is good, simple installation, reliable quality, loved by consumers.


    Existing reviews of 370W AC Vibration Motor, 3 Phase, 4 Pole
    The most cost-effective vibration motor
    It is a copper-core motor when it is disassembled. It has strong vibration when installed on the machine, is dust-proof and waterproof, and can run continuously for a long time.
    From: Otis | Date: 10/05/2022
    Was this review helpful? Yes No (0/0)
