    15V Desktop AC to DC Adapter, 45W-150W, 3A-10A

    $36.51
    Competitive price desktop AC adapter with 15V output voltage, rated power 45W/ 60W/ 75W/ 90W/ 120W/ 150W, output current 3A/ 4A/ 5A/ 6A/ 8A/ 10A for selection. It is widely used in industrial automation control, industrial control equipment, power equipment, medical equipment, air purifiers and other fields.
    SKU: ATO-SPF-015
    *
    *
    Free Shipping Worldwide
    Delivery date: 6-12 days

    15V desktop AC/DC power supply for sales, with 50/ 60Hz frequency, 3000mA/ 4000mA/ 5000mA/ 6000mA/ 8000mA/ 10000mA capacity can be chosen. It has advantages of high efficiency, tough wire material and durable.

    Specification

    Series 15V
    Model SPF-015
    Rated power 45W/ 60W/ 75W/ 90W/ 120W/ 150W
    Output voltage 15V DC
    Output current 3A/ 4A/ 5A/ 6A/ 8A/ 10A
    Input voltage 100-250V AC
    Frequency 50/ 60Hz
    DC port size 5.5*2.5mm (compatible 5.5*2.1mm)
    Efficiency 98%
    Shell material Fireproof plastic enclosure
    Colour Black
    Capacity 3000mA/ 4000mA/ 5000mA/ 6000mA/ 8000mA/ 10000mA
    Input ripple ≤80mV
    Applicable equipment Computer/ switch/ router/ access control system/ CCTV etc.
    Size 131*56*36mm
    Weight ≤1kg
    Certificates CE, FCC, ROHS, CCC
    Plug GB/ US/ EUR/ JPN/ UK/ GER/ AUS
    Warranty 2 years

    Dimension (unit=mm)

    DC port size of desktop AC adapter

    Tips: The Differences Between Wall AC Adapters and Desktop AC/DC Adapters.

    The power adapter is divided into a wall-mounted power adapter and a desktop AC adapter. The wall-mounted power adapter is also called a wall-mounted power adapter. In fact, it can be explained simply. The wall-mounted power adapter is the main body that can be directly plugged into the plug-in board. Power adapter. The desktop AC adapter is the power adapter that the body needs to be placed on the desktop. The difference between the desktop AC adapter and the wall-mounted power adapter is that the desktop power adapter requires an AC cord to be connected to the mains.

    Power adapters are widely used in security products, communication products, and small home appliances and consumer electronic products. Especially in portable consumer electronics and communication products, they are generally within 10W. For example, smart phones and tablet computers generally use 5-10W power adapter for power supply, while computer peripherals, security products, and small home appliances generally use power adapters below 36W, especially today when energy is tight and energy conservation and environmental protection are advocated, products in this power section are the most common. And notebooks, TVs and other products are generally Use the power adapter below 120W, and the built-in power supply is more than 100W. However, there are also external power adapters below 200W. However, the number is relatively small.
