    5A 60V 300W Variable Linear DC Power Supply

    Factory price 0 to 5A, 0 to 60V variable linear DC power supply is switching mode with 300W DC output. Output voltage and current are adjustable, with 110V/220V±10% AC input, constant voltage (CV) / constant current (CC) output precision and high efficiency. This versatile device features adjustable voltage and current settings, allowing users precise control over their power requirements.
    SKU: ATO-DCPS605
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    60 volt 5 amp variable linear DC power supply caters to a diverse array of applications in electronics, prototyping, and testing. Its linear configuration plays a pivotal role in minimizing output noise, thereby augmenting the stability of interconnected circuits. This adjustable linear DC power supply offers precise adjustments for voltage and amperage settings, ensuring optimal performance and safety for connected devices.


    Model ATO-JK605S
    Input Voltage 110V or 220V AC (+/- 10%)
    Output Voltage Range DC 0-60V
    Output Current Range 0-5A
    Output Power 300W
    Frequency 50Hz/60Hz
    Output Type Dual
    Display 3 digit
    Display Accuracy ≤ ±0.1%+2d
    Voltage Display Resolution 100mV
    Current Display Resolution 100mA
    Efficiency >65%
    Voltage Regulation
    Load Regulation (CV) 1×10-1+3mV
    Line Regulation (CV) 1×10-1+8mV
    Ripple & Noise (P-P) 0.5mV
    Temperature Coefficient 300PPm/℃
    Current Regulation
    Load Regulation (CC) ≤5mA
    Line Regulation (CC) 2×10-1+3mA
    Temperature Coefficient 500PPm/℃
    Protection Over Load and Over Voltage Protection
    Recovery Time ≤100µs
    Operating Ambient 0℃ to + 40℃/ 85%RH
    Storage Ambient -10℃ to + 80℃/ 80%RH
    Warranty 12 Months
    Size 290 (L) x 130 (W) x 165 (H) mm
    Weight 5.5kg


    5A 60V variable linear DC power supply detail

    Tips: Are there any maintenance tasks I need to perform on a variable linear DC power supply?

    Regular maintenance is essential for optimal performance of a variable linear DC power supply. Periodically check and calibrate voltage and current settings using a reliable multimeter. Inspect the cooling system for dust and debris, cleaning as necessary to prevent overheating. Verify proper ventilation to ensure efficient cooling. Examine the input and output terminals for any loose connections or signs of wear. Inspect the power supply for physical damage and address any issues promptly. Regularly test the power supply under load conditions to confirm stability and accuracy. Follow the manufacturer's guidelines for maintenance intervals and procedures outlined in the user manual. Adhering to a routine maintenance schedule will enhance the longevity and reliability of your variable linear DC power supply.
