    100 ton Hydraulic Bottle Jack

    $473.88
    Competitive price 100 ton hydraulic jack for sale online. It is a bottle jack that uses hydraulic power to lift heavy loads. Works with a hydraulic pump, suitable for lifting in power maintenance, bridge maintenance and so on.
    *
    SKU: ATO-HBJ-100
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    The provided hydraulic jack is used for lifting heavy objects efficiently and safely. Low price 100 ton hydraulic bottle jack comes with a 100mm stroke, smaller size and enough capacity, widely used in power maintenance, bridge maintenance and heavy lifting.

    Features

    • Hydraulic bottle jack with 100 ton capacity is designed for lifting heavy loads.
    • Blackening of the plunger surface to protect the using of the longevity of the product.
    • The plunger has the function of retracting automatically.
    • The joint of the hydraulic bottle jack adopts a threader ZG3/8" fast connector, thread locking, and compact structure.
    • 100 ton hydraulic jack is suitable for a variety of environments, commonly used in electric power, chemical industry, steel, machinery, industry and so on.

    Specifications

    Hydraulic Bottle Jack Model ATO-FCY-100100
    Tonnage 100 ton
    Self Height 172mm
    Stroke 100mm
    Outer Diameter 178mm
    Inner Diameter 110mm
    Weight 26.5kg
    Effective Area 143.06cm
    Matched Hydraulic Pump CP-700-2
    Matched Hydraulic Jack Pump Model ATO-CP-700-2
    Standard Tubing Length 1.7m
    High Pressure 700kg/cm2
    Low Pressure 20kg/cm2
    High Pressure Flow 2.3CC
    Oil Storage Capacity 2700CC (No. 15 Anti-Wear Hydraulic Oil)
    Low Pressure Flow 13CC
    Weight 15kg


    Details

    Hydraulic jack details

    *Notes

    • This hydraulic jack is not recommended for cars.
    • In order to operate correctly all cylinders need to be connected to a solid lifting surface.
    • Cylinder damage can result from the use of cylinders on sandy, earthen or loose surfaces.

    Notes of hydraulic jacks

    Applications

    At present, 10 to 200 ton hydraulic jacks are widely used in power maintenance, bridge maintenance, heavy lifting, static pile pressing, foundation settlement and bridge, especially in road and railway construction, mechanical adjustment, and equipment dismantling.

    Hydraulic jack applications

    Tips: How to maintain a hydraulic jack?

    • The bottom of the hydraulic jack should be flat and hard when used. The oil-free wooden board expands the pressure-bearing surface to ensure safety. Iron boards cannot be used instead of wooden boards to prevent sliding.
    • It is required to be stable when lifting. After lifting the heavy object for a while, check whether there is any abnormality. If there is no abnormality, continue to lift the top. Do not lengthen the handle arbitrarily or operate it excessively.
    • Not overloaded, super high. When the red line appears on the sleeve, it indicates that the rated height has been reached and the jacking should be stopped.
    • When several hydraulic jacks are operating at the same time, there must be a special person to command, so that the lifting or lowering can be carried out synchronously. Wooden blocks should be supported between two adjacent hydraulic jacks to ensure intervals to prevent slipping.
    • When using a hydraulic jack, always pay attention to the sealing part and the pipe joint part, and must ensure their safety and reliability.
    • Hydraulic jacks are not suitable for places with acid, alkali or corrosive gas.

    Hydraulic bottle jack dimensions

    SKU Tonnage (t) Self Height (mm) Stroke (mm) Outer Diameter (mm) Inner Diameter (mm) Weight (kg)
    ATO-HBJ-10 10 156 100 63 38 3.5
    ATO-HBJ-20 20 156 100 84 50 6.2
    ATO-HBJ-30 30 162 100 104 60 9.6
    ATO-HBJ-50 50 162 100 128 80 12.6
    ATO-HBJ-100 100 172 100 178 110 26.5
    ATO-HBJ-150 150 180 100 205 135 50
    ATO-HBJ-200 200 202 100 238 160 65
