2 HP (1.5 kW) Automatic Water Pressure Booster Pump

5 out of 5 based on 2 reviews | Write a review
$501.29
2 HP (1.5kW) automatic water booster pump for sale to increase water pressure, single phase, 220V-240V 50Hz, 1-1/2 in. water inlet and outlet diameter, max. head 60m, max. flow 100 LPM. This self-priming pump is mainly used for home, washing machine, water tank and water purifier.
SKU: ATO-BP-2HP
30-day Returns
Free Shipping
Delivery date: 6-12 days

2 HP (1.5 kW) water pressure booster pump is a combination of motor, pump, pressure tank, pressure switch, flow sensor switch and electronic controller for the integration of automatic water supply system. It widely used in house, bathroom, washing machine, sprinkler system, irrigation system and reverse osmosis (RO) system.

Specification

Model ATO-40WZB-1500A
Power 2 HP (1.5 kW)
Voltage (AC) 220V-240V
Frequency 50Hz
Phase Single Phase
Max. Flow 100 L/min
QMax 4.8 - 5.0 m3/h
Max. Head 60m
Max. Suction 9m
Inlet Diameter 1-1/2 inch
Outlet Diameter 1-1/2 inch
Pump Max. Liquid Temperature +0 ~ +80℃
Liquid PH Valve 6.5 - 8.5
Material Cast Iron Body and Support
Motor Max. Ambient Temperature +40℃
Insulation Class B or F
Protection IP x 4
Cooling External Ventilation
Shaft Stainless Steel Welded Shaft / 45# Steel Shaft
Packing Dimension 365mm * 270mm * 365mm
Weight 21kg

Details

Details of  2 HP (1.5 kW) Automatic Water Booster Pump

Applications

Single Phase Automatic Water Booster Pump ApplicationsTips: How to select an automatic water booster pump?

There are a number of factors causing water pressure problems, if the water tank water pressure is insufficient in the old house, you can solve the problem by installing a booster pump. But how to choose a suitable water booster pump Now we recommend you to choose it according to its technical parameters.

  • Motor power
    In the case of the same flow head, the low power of the motor equipment is good.
  • Rated flow
    The rated flow is the maximum amount of water that can be used in a given water service If the flow is not sufficient, the water pressure may be low or no water at peak times. Peak water pressure can be guaranteed only when the rated flow is greater than or equal to the maximum possible water consumption for our water use.
  • Rated head or pressure
    The rated pressure is the maximum pressure that the booster pump can reach when operating at the rated flow. The max. pressure here must be at the rated flow, rather than the max. pressure when the outlet is closed.

In short, you must know about the actual parameters of water booster pump in detail from retailers and manufactures, and then choose according to your actual production needs.
