    Rotary Green Laser Level, 3 Line, 360 Degree

    ATO 3-line green laser level for sale with 2 vertical line, 1 horizontal line, 1 plumb dot and 3 bright dots, the self-leveling range is ±3°. The rotary laser level with 360° rotary heavy-duty aluminum alloy base makes it easier to adjust the laser lines' positions.
    SKU: ATO-LL-03
    30-day Returns
    Delivery date: 6-12 days

    Rotary green laser level with 3 lines, 5m±1mm horizontal/vertical accuracy. The rotary green laser level with IP54 waterproof/dustproof to ensure that you can work normally and stably under complex working conditions.


    Model: ATO-SL-03
    No.of Laser Lines: 3 line
    Horizontal Accuracy: 5m±1mm
    Laser Wavelength: 635nm
    Self-Leveling Range: ±3°
    Launch Angle: ≥120°
    Leveling Type: 2 vertical line, 1 horizontal line, 1 plumb dot, 3 bright dots

    Vertical Accuracy: 5m±1mm
    Plumb Dot Accuracy: ±1mm at 1.5m
    Line Width: 2mm
    Line Color: Emerald green
    Power Supply: 3 * AA batteries or AC power
    IP Rating: IP 54
    Operation Temperature: 0℃~40℃
    Laser Head: Made in Germany

    Operating Temperature: 10℃~50℃
    Weight: 2.5kg
    Laser Tube Life: 10 years
    Outdoor Visible Distance: About 15m
    Indoor Visible Distance: About 15m~40m
    Application: Ceiling, home decoration, door and window installation, etc.
    Function Key: Fingerprint touch buttons
    Battery Type: Digital LCD rechargeable lithium battery (8 hours standby)

    3 Line Laser Level Diagram

    3 line rotary laser level diagram


    Rotary laser level detail


    ATO high-intensity laser level is a common measuring tool for measuring angles. The high-precision green light level can be widely used in metallurgical steel plate cutting, stone cutting, wood cutting, machine vision, and other fields.

    Rotary laser level application

    Tips: What is a laser level?

    The laser level is a level that guides the laser beam emitted by the laser device into the telescope barrel of the level so that it is emitted along the collimation axis. There are two types of laser level: a special laser level and a laser device attached to the level. It can be used for leveling measurement by cooperating with a leveling rod equipped with a photoelectric receiving target. Compared with the optical level, the laser level has the characteristics of high precision, long line of sight and automatic reading and recording.
