    1" Brass Ball Valve with Handwheel

    5 out of 5 based on 1 reviews | Write a review
    1 inch brass ball valve with handwheel for sale at low price, DN25, 1.6MPa, double acting. This fixed forged brass ball valve can be used to control water, oil, non-corrosive and non-combustible gas, etc.
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Factory price 1 inch threaded brass ball valve with handwheel is used for water and flow control. This manual ball valve has good sealing performance and a good flow adjustment function.


    • Model: ATO-BBVH-DN25
    • Nominal Diameter: DN25
    • Nominal Pressure: 1.6MPa
    • Size: 1 inch
    • Body Material: Brass
    • Connection Type: Thread
    • Standard: Compliant with ISO 228 Standard
    • Structure: Fixed Ball Valve
    • Applicable Temperature: -10℃≤T≤120℃
    • Valve Action: Flow Control
    • Mode of Action: Double Acting
    • Channel Location: Straight
    • Sealing Material: Rubber
    • Sealing Method: Soft Seal
    • Drive Mode: Handwheel
    • Flow Direction: Bidirectional
    • Working Medium: Water, Oil, Non-Corrosive and Non-Combustible Gas
    • Weight: 410g

    Dimensions & Details (Unit: mm)

    Dimensions of brass ball valve with handwheel

    DN Size A B C H L
    25 1 60 14 21.5 90 49
    Number 1 2 3 4 5 6 7 8 9 10 11
    Component Valve Body Valve Plate Valve Stem Gasket Valve Cap Locking Cap Filler Pressure Cap Handwheel Brand Hex Nut
    Material Brass Brass Brass PTFE Brass Brass PTFE Brass Iron Aluminum Stainless Steel

    Tips: What is brass ball valve used for?

    Brass ball valves are mainly used to cut off, distribute and change the flow direction of the medium on the fluid in the pipeline. The ball valves designed as V-shaped openings also have good flow regulation function. Brass ball valve is evolved from the cock, its opening and closing parts as a ball, using the ball to rotate 90° around the axis of the stem to achieve the purpose of opening and closing.
