    200Amp Stick Welder, DC Dual Voltage 110V/220V

    $860.26
    120V stick welder at a cheap price, 200A, best stick welder dual voltage 110V or 220V is available, automatic dual frequency 50Hz 60Hz, dc miller welding machine allows the user to easily switch from 220V to 110V with the included adapter plug.
    SKU: ATO-WM-TIG200
    *

    Mig welder for sale, 200 amp, 50/60Hz, 110V 220V DC voltage can be selected, stick welding machine can be used for welding stainless steel, mild steel, aluminum and other metal material.

    200A Stick Welder Specifications

    Model ATO-TIG200A
    Input Voltage DC 110V/220V, +/15%, 1-PH, 50Hz/60Hz (Automatic dual frequency)
    Input Current 7A at 110V,
    34A at 220V
    Output Current 10-190A at 220V, 10-120A at 110V
    Power 5.7 kVA
    Power Factor 0.73
    Duty Cycle at 40℃(104℉) 60%
    Frequency 50Hz/60Hz (Automatic dual frequency)
    Recommended gas inlet flow rate / pressure 3.6scfm at 65psi
    Dimension 771mm*330mm*432mm
    Weight 17kg
    Cutting Material Mild Steel, Stainless Steel, Aluminum, etc
    Welding Thickness 6mm
    Gas Supply Clean, Dry, Oil-Free Argon
    Color Red
    Warranty 12 Months

    Stick Welder Package Includes
    1. TIG torch TT132 (13ft long, 2 pin connection).
    2. TIG torch accessories similar to model TA01 (includes: 2 pieces of shield cups, 2 collets, 1 collet body and 1 DC tungsten tlectrode stick).
    3. Stick welding electrode holder (9ft long). Ground cable & clamp (6ft long). Argon hose (4ft long).
    4. Foot pedal FP23 (3 pin connection).
    5. Pigtail adaptor PT02 (converts 220V to 110V).
    6. Hand held shield with cleaning wire brush and user manual.

    200A Stick Welder Features:
    1. 200 Amp DC square-wave inverter TIG/STICK (MMA) welder
    2. Automatic dual voltage/ dual frequency (110/220Volt 50/60Hz)
    3. High frequency start hand torch control and precise foot pedal welding heat control
    4. Suitable for welding stainless steel, mild steel, aluminum and other metal materials.

    Portable Welder 110V 220V Structure

    Miller welder structure

    Tip: Stick Welder Working Principle
    The stick welder uses the high-temperature arc generated by the positive and negative poles in an instantaneous short-circuit to melt the solder and the material to be welded on the electrode to achieve the purpose of combining them. The structure is very simple, it is a high-power transformer. The welding machine can be divided into two types according to the type of output power. One is AC stick welder, and the other is DC stick welder.
