    32 amp 2 pole Miniature Circuit Breaker

    5 out of 5 based on 1 reviews | Write a review
    $64.69
    32 amp 2 pole miniature circuit breaker is designed for short circuit and overload protection for the branch circuit and equipment with high performance in rated short-circuit breaking capacity 6kA at 230/400V AC. This C32 MCB with C curve trip characteristic can meet the different needs of applications.
    SKU: ATO-MCB-2P32
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    32 amp miniature circuit breaker (MCB) with double pole is designed to provide reliable overload and short-circuit protection in electrical circuits. This mini circuit breaker is commonly used for branch circuit protection in residential settings, ensuring the safety of wiring and connected devices.

    Double Pole MCB Breaker Information

    • Rated Current: 32 amp
    • Rated Voltage: 230/400V AC, 50Hz
    • Number of poles: 2 poles
    • 6 kA rated short-circuit breaking capacity
    • Compliant with IEC standard
    • C curve trip characteristic
    • With overload protection and short circuit protection function

    Technical Data

    Model ATO-NB8-632PC32
    Rated Current 32A
    Rated Voltage 230/400V
    Frequency 50Hz
    Number of Poles 2P
    Mechanical Life 20000 Times
    Electrical Life 10000 Times
    Rated Short-Circuit Breaking Capacity 6000A
    Operating Short-Circuit Breaking Capacity 6000A
    Rated Impulse Withstand Voltage (1.2/50) 6kV
    Dielectric Test Voltage 2000V (50Hz, 1 min)
    Heat & Humidity Resistance 28 Cycles
    Vibration Resistance No Obvious Vibration and Impact
    Terminal Block Terminal Block Type Pillar Terminal Block
    Min. Terminal Size Acceptability 1mm2
    Max. Terminal Size Acceptability 25mm2
    Standard Connection Torque 2 N.m
    Max. Tolerable Torque 2.5 N.m
    Wire Insertion Depth 13mm
    Reference Temperature 30℃
    Operating Temperature -35℃~+70℃
    Storage Temperature 35℃~+85℃
    Applicable Altitude 2000m
    Tripping Mode Thermal Magnetic Trip
    Electromagnetic Tripping Type Type C (5In-10In)
    Shell Flame Retardant Grade V0
    Wire Entry Method Both Upper and Lower
    Installation Method TH35-7.5 Standard Rail
    Protection Level Direct Installation IP20B
    Installed in the Distribution Box IP40B


    Double Pole MCB Breaker Dimensions (Unit: mm)

    32 amp 2 pole Miniature Circuit Breaker Dimensions

    Details

    2 pole Miniature Circuit Breaker Details

    Tips: Difference between the circuit breaker and air switch

    1. Voltage level: As to the low-voltage apparatus, the air switch is equivalent to the circuit breaker. As to the apparatus with a voltage grade below 500V, when there is a short circuit, the current can be cut off. In the high-voltage apparatus, the two are different. The circuit breaker can operate normally in various voltages above 220V. Its sustained load and short-circuit current are higher. However, the air switch will be cut off automatically if the current exceeds a certain value.
    2. Arc extinguishment means: The air switch extinguishes the arc with air as the medium. Therefore, it is also named the air-type low-voltage circuit breaker. Because it has convenient operation and high safety, it is widely used. The circuit breaker has many arc extinguishing means. So, its arc extinguishing capacity is strong. The high-voltage apparatus usually employs the vacuum, sulfur hexafluoride for arc extinguishing.
    3. The effects: The air switch usually plays the role of “isolation” and “protective equipment” in the small-current circuit. In the condition of short-circuit current and high current, the circuit breaker trips automatically. In the high-voltage and high-current circuit, it is normally used as the operating apparatus for powering off, powering on, connecting, and disconnecting the load.

    Types of Circuit Breakers

    In this video, we'll take a closer look at the meaning behind these abbreviations and explain the types of circuit breakers they represent. By understanding the different types of circuit breakers on the market, you can make an informed decision and choose the right type for your specific requirements, thereby enhancing the protection of your electrical infrastructure.

    Isolator vs Circuit Breaker

    Although isolators and circuit breakers have similar functions in a circuit, they are two separate entities. This video explains you the difference between the two devices in terms of working, features, operation, affordability, etc. You can choose between them based on your specific requirements.
