    4" Brass Ball Valve with Handwheel

    Industrial 4 inch brass ball valve with handwheel for water, oil, non-corrosive and non-combustible gas, DN100, 1.6MPa, double acting. This fixed forged brass fixed ball valve at low cost with soft seal is perfect for flow control.
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    This manual valve is made of high-quality brass forging to prevent leakage. Brass ball valve is manufactured by a high-precision special machine with low flow resistance. The medium inside the valve body has a straight channel, and the medium flows in a straight line.


    • Model: ATO-BBVH-DN100
    • Nominal Diameter: DN100
    • Nominal Pressure: 1.6MPa
    • Size: 4 inch
    • Body Material: Brass
    • Connection Type: Thread
    • Standard: Compliant with ISO 228 Standard
    • Structure: Fixed Ball Valve
    • Applicable Temperature: -10℃≤T≤120℃
    • Valve Action: Flow Control
    • Mode of Action: Double Acting
    • Channel Location: Straight
    • Sealing Material: Rubber
    • Sealing Method: Soft Seal
    • Drive Mode: Handwheel
    • Flow Direction: Bidirectional
    • Working Medium: Water, Oil, Non-Corrosive and Non-Combustible Gas
    • Weight: 4860g

    Dimensions & Details (Unit: mm)

    Dimensions of brass ball valve with handwheel

    DN Size A B C H L
    100 4 140 22.5 73 220 91
    Number 1 2 3 4 5 6 7 8 9 10 11
    Component Valve Body Valve Plate Valve Stem Gasket Valve Cap Locking Cap Filler Pressure Cap Handwheel Brand Hex Nut
    Material Brass Brass Brass PTFE Brass Brass PTFE Brass Iron Aluminum Stainless Steel

    Tips: What advantages can brass ball valve bring?

    1. Good sealing performance: Since the sealing of the hard-sealed ball valve is artificially ground, it cannot be used until the valve core and the sealing ring are completely matched. So his sealing performance is reliable.
    2. Light switch: Since the bottom of the sealing ring of the hard-sealed ball valve adopts a spring to hold the sealing ring and the valve core tightly together, the switch is very light when the external force exceeds the preload of the spring.
    3. Long service life: It has been widely used in petroleum, chemical industry, power generation, papermaking, atomic energy, aviation, rocket and other departments, as well as people's daily life.
