Portable pressure gauge is designed for measuring water pressure, hydraulic pressure, oil pressure and air pressure, can provide 0 to 15 psi and 0~1 bar measuring range, 40mm dial diameter, and stainless steel for waterproofing. Dual-scale diaphragm pressure gauge has a 1/8" BSPT thread specification, widely used in mining, smelting, medical treatment, maintenance, etc.
- Model: ATO-TS-Y408-15psi
- Dial Diameter: φ40mm
- Installation Method: Radial
- Range: 0~15 psi, 0~1 bar
- Installation Diameter: 1/8
- Thread Specification: BSPT
- Size: 6x4x2.5cm
- Material: Stainless Steel
- Package Size: 8.5x6.5x4.5cm
- Product Weight: 44g
- Package Weight: 60g
- 0 to 15 psi pressure gauge can be used as a water pressure gauge, air pressure gauge, hydraulic pressure gauge and oil pressure gauge.
- ATO pressure gauge equipped with dual scale (0~15 psi/0~1 bar), and a lower-mount male connection with a 1/8" BSPT thread.
- The circular dial is enclosed in a stainless steel case for corrosion resistance, portable 0~1 bar pressure gauge offers clear readings and is weather-resistant.
- Display accuracy of 2.5% over the entire range of the gauge.
- Brass and stainless steel wetted parts for measuring non-corrosive liquid and gas pressure. Such as water, oil, fuel, coolant, air, co2, nitrogen, and argon pressure test.
Dimension (Unit: mm)
Pressure gauge is the most commonly used measuring instrument for displaying and controlling pressure, widely used in the chemical industry, petroleum, metallurgy, mining, and electric power production, especially in vehicle maintenance shops, heat pipe networks, water and gas supply systems, etc.
Tips: What is a pressure gauge?
A pressure gauge refers to an instrument that uses elastic elements as sensitive elements to measure and indicate pressure higher than the environment. It is used in almost all industrial processes and scientific research fields, mainly in heat pipe networks, oil and gas transmission, water and gas supply systems, and vehicle maintenance. Maintenance shop, etc. Especially in the process of industrial process control and technical measurement, mechanical pressure gauges are becoming more and more popular due to the high mechanical strength and convenient production of the elastic sensitive components of mechanical pressure gauges.
