    100 MHz PC Based Oscilloscope, Four Channel, 1 GSa/s

    5 out of 5 based on 1 reviews | Write a review
    $1,062.06
    Reasonable price 100 MHz PC-based oscilloscope is a high-accuracy digital oscilloscope with 4-channel, 1 GSa/s sampling rate, one computer could connect with multiple oscilloscopes, expand the channel number easily, and more than 20 kinds of automatic measurement functions.
    *
    SKU: ATO-PBO-100F
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    PC oscilloscope with 100 MHz bandwidth, 1 GSa/s sampling rate, 8 bits vertical resolution 40V Max input voltage. High-accuracy PC-based oscilloscope has high technical performance, strong scalability, less development time, and excellent integration four advantages.

    Specification

    Model ATO-VDC-3104 ATO-VDC-3104L
    Communication Interface USB2.0

    USB 2.0 (with LAN network port)

    Bandwidth 100 MHz
    Channel 4 Channel+ Multi
    Sample Rate 1 GSa/s
    Max. Input Voltage 40V(DC + AC peak)
    Horizontal Scale (s/div) 2ns/div - 100s/div, step by 1 - 2 - 5
    Record Length 5M
    Input Impedance 1MΩ ± 2%, in parallel with 10pF ± 5pF
    Vertical Sensitivity 5mV/div - 5V/div
    Vertical Resolution 8 bits
    Trigger Type Edge, Pulse, Video, Slope, and Alternate
    Automatic Measurement Vpp, Vavg, Vrms, Frequency, Period, Vmax, Vmin, Vtop, Vbase, Vamp, Overshoot,
    Pre-shoot, Rise Time, Fall Time, +Width, -Width, +Duty, -Duty, DelayA→B , DelayA→B
    Waveform Math +, -, *, /, FFT
    Power Supply ≤6.5W
    Dimension (W * H * D) 190* 18* 120mm
    Weight 0.3 kg



    Accessories

    • CD ROM
    • USB cable
    • Probe
    • Probe Adjust
    • Silicon Gel Case
    • Quick Guide

    Dimension (mm)

    PC based oscilloscope dimension

    Tips: What are the advantages of a PC-based oscilloscope?

    Compared with stand-alone oscilloscopes, PC-Based USB Oscilloscopes have the following advantages:

    • Small size, easy to carry.
    • PC screen is larger so the waveforms can be seen more clearly.
    • No screen component so the price is lower.
    • PC interface makes it easy to process and edit files.
    • Users can design their own programs to control the oscilloscope.
    Existing reviews of 100 MHz PC Based Oscilloscope, Four Channel, 1 GSa/s
    Portable oscilloscope
    This PC oscilloscope directly relies on the PC for data processing. Compared with traditional desktop oscilloscopes, it is smaller in size and does not take up much desktop space, making it suitable for scenarios that require mobile testing.
    From: Ulase | Date: 17/02/2025
