    4μF 450V Ceiling Fan Capacitor

    $2.69
    2 Wire capacitor for ceiling fan, capacity value 4μF, 450V AC and 50/60Hz rating, capacitance tolerance 5%, ceiling fan capacitor can be applied to different types of ceiling fan motors for start and stop.
    SKU: ATO-FC-CBB61-040
    This product has a minimum quantity of 100
    Free Shipping Worldwide
    Delivery date: 10-12 days

    Buy square ceiling fan capacitor with 4 mfd capacity online, rated voltage 450V AC, CBB61 type capacitors are suitable for starting and running of various electrical appliances motors with 50/60Hz AC power supply frequency.

    Specification

    • Model: ATO-FC-CBB61-040
    • Capacity: 4μF
    • Rated Voltage: 450V
    • Tolerance: ±5%
    • Withstand Voltage: 2. 0 Un (2s)
    • Loss: (DF)≤0.0010 100Hz
    • Insulation Resistance: CxRs≥3000S (23℃, 1000VDC, 1min)
    • Rated Frequency: 50/60Hz
    • Climate Category: 40/105/21
    • Scope of Application: Start, run
    • Appearance: Rectangular
    • Lead Out Method: Cord, pin, insert
    • Dielectric Material: Organic thin film
    • Dimension: 47(W) x 17(L) x 31(H)mm
    • Certificate: CE, CQC

    4μF Ceiling Fan Capacitor Wiring Diagram

    Ceiling fan capacitor circuit diagram

    Ceiling fan capacitor details

    Ceiling fan capacitor detail

    Tips: What are the common problems of home electric fans?

    1. The speed switch is stuck and rusted, add lubricant to solve.
    2. The electric fan will not swing the head, swing motor damage, replace the swing synchronous motor to solve.
    3. The electric fan is very noisy and has vibration, caused by the deformation of the wind blade, replace the wind blade to solve.
    4. The electric fan motor connector is broken, replace the plastic connector with a new one.
    5. Electric fan swing head function is not, check the swing switch is not damaged, replace.
