    15 kVA Single Phase Variac Voltage Regulator

    5 out of 5 based on 2 reviews | Write a review
    $2,079.09
    Good performance variac transformer, 15 kVA and single phase for generator, the rated output current is 48A and rated output voltage is 0-250V. Direct sale by factory and convenient for you.
    SKU: ATO-VVR-15K
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    Single phase variac transformer for sale, 15 kVA cpacity, smooth pressure regulation, light weight, other capacity can be customised.

    Note: Support the split phase (L1,L2+N,G), Please contact us.

    15 kVA Single Phase Variac Voltage Regulator Features

    • The rated output voltage is 0-250V and Rated input voltage is 220V.
    • The rated output current is 48A.
    • With 15 kVA power, 1 phase.
    • Widely used in various power supply places with frequency 50 Hz.
    • High quality and long life variac voltage regulator.

    15 kVA Single Phase Variac Voltage Regulator Specifications

    Model TDGC2-15K
    Phase No 1
    Frequency 50/60Hz
    Rated Input Voltage 220V
    Rated Output Voltage 0-250V
    Rated Capacity 15 kVA
    Max Output Current 48A
    Usage SVC
    Current Type AC
    Actual Output Current (actual output voltage * rated current) / maximum output voltage
    Type Contact type regulators
    Weight 46g
    Dimension L 370mm
    W 310mm
    H 640mm

    15 kVA Single Phase Variac Voltage Regulator Detail

    15 kVA single phase variac voltage regulator

    Tips: Principle of single-phase voltage regulator

    Principle: A voltage regulator is a self adjustable transformer with continuous turn ratio. When the voltage regulator brush functions from the handwheel spindle and brush holder, slide along the polished surface of the circle and the turn ratio can be continuously changed, thus adjusting the output voltage smoothly to the maximum value.

    Existing reviews of 15 kVA Single Phase Variac Voltage Regulator
    Variac transformer is sturdy and works as described
    The variable regulator transformer is heavy and very well made. I need to use both hands to pick it up. The 15kVA varaic voltage regulator with my router, buffer and angle grinder and works very well with all tools.
    From: Lay | Date: 10/02/2023
    Was this review helpful? Yes No (0/0)
    Do you provide a 60Hz variac voltage regulator?
    On your web site, we see that all your variac voltage regulators are 50Hz. Do you provide 60Hz as well?
    From: Mandykat | Date: 23/08/2021
    Was this review helpful? Yes No (0/0)
    ATO Responded
    Yes, we provide 60Hz varaic voltage regulator but our variac configuration is 1-phase, one hot line (L,N,G).
