Displacement Sensor

View as Grid List

Display per page

Sort by

4mm Eddy Current Displacement Sensor, Φ 11mm Probe

4mm Eddy Current Displacement Sensor, Φ 11mm Probe

$593.69

SKU: ATO-ECDS-411

Buy eddy current displacement sensor at affordable price. Measuring range 4mm, probe diameter 11mm, selectable output signal 0～5V/10V voltage, 4～20mA current and RS485, corresponding max working current 45/25/40mA, DC power supply, linear error ≤±0. 5 %. Non-contact inductive eddy current transducer, vibration measurement is available.

5mm Eddy Current Displacement Sensor, Φ 16mm Probe

5mm Eddy Current Displacement Sensor, Φ 16mm Probe

$609.08

SKU: ATO-ECDS-516

Eddy current displacement sensor has a Φ 16mm probe. Measurement range 5mm, optional output signal 0-5V/10V voltage, 4-20mA current and RS485, corresponding max current 45/25/40mA, DC working voltage, max linear error ±0. 5 %. Eddy current transducer can measure linear displacement and vibration, inductive type, non-contact measuring, competitive price.

12.5mm Eddy Current Displacement Sensor, Φ 25mm Probe

12.5mm Eddy Current Displacement Sensor, Φ 25mm Probe

$624.46

SKU: ATO-ECDS-12525

Economical price Eddy current sensor from professional manufacturer, linear displacement measurement. Measuring range 12.5mm, probe diameter 25mm, output signal supports 0-5V/10V voltage, 4-20mA current and RS485, corresponding max working current 45/25/40mA, DC power supply, linear error ≤±1 %. Eddy current displacement transducer, inductive type, non-contact measurement, easy use.

25mm Eddy Current Displacement Sensor, Φ 50mm Probe

25mm Eddy Current Displacement Sensor, Φ 50mm Probe

$639.85

SKU: ATO-ECDS-2550

Eddy current sensor working for linear displacement and vibration measurement. Measuring range 25mm, probe diameter 50mm, output signal available in 0-5V/10V voltage, 4-20mA current and RS485, maximum operating current 45mA, DC power supply, linear error ≤±1 %. Eddy current displacement transducer is inductive non-contact type, small size, compact structure, ideal price.

50mm Eddy Current Displacement Sensor, Φ 60mm Probe

50mm Eddy Current Displacement Sensor, Φ 60mm Probe

$686.31

SKU: ATO-ECDS-5060

Eddy current displacement sensor working with a Φ 60mm probe and proximitor. Measurement range 50mm, output signal 0-5V/10V voltage, 4-20mA current and RS485 for selection, maximum current 45/25/40mA, DC power supply, max error 2%. Eddy current transducer with competitive price, ideal for inductive non-contact measurement of linear displacement and vibration.

Displacement sensors, also known as linear sensors, are divided into inductive displacement sensors, capacitive displacement sensors, photoelectric displacement sensors, ultrasonic displacement sensors, Hall-type displacement sensors and magnetostrictive displacement sensors. The function of displacement sensor is to convert a mechanical displacement into an electrical signal, and this signal can be proportional to the mechanical movement. Displacement sensor has default resistance signal output, and also can output voltage and current signals through displacement transmitter.
