    2500VA Toroidal Transformer, 120V AC to 12V/40-0-40V

    HIgh quality 2500VA (2500W) toroidal transformer for power amplifier, high insulation strength, UL recognised, compact structure make efficiency >90%. Single 120V/50-60Hz primary winding, designed to step down 120V to 12V/ 40-0-40V secondary voltage.
    SKU: ATO-T-C2500VA
    30-day Returns
    Free Shipping
    Delivery date: 6-12 days

    The provided cheap price toroidal transformer is 2500VA, works at 50Hz/ 60Hz low frequency circuit, with a primary voltage of 120V AC and twin secondary voltage of 2x40V, twin secondary windings may be connected in series or parallel or used independently.

    Advantages of ATO Toroidal Transformer

    1. High Efficiency: Winding matches core perfectly, which makes the transformer more efficiency.

    2. Long Service Life: With high quality materials and manufacturing technology, the transformer can be used for 30 years.

    3. Less Noise: The core is seamlessly rolled and the winding is set evenly over it, which makes the transformer quiet when it is working.

    4. Less Radiation: Toroidal structure and winding technology reduce electromagnetic radiation.

    5. Low Temperature Rise: Even it is overloaded at 120%, temperature rise will be less than 70℃.

    2500VA Toroidal Transformer Specifications

    Model ATO-C2500VA
    Phase Single phase
    Power 2500VA (2500W)
    Primary Voltage 120V AC (Optional: 110V, 120V, 220V, 230V, 240V)
    Secondary Voltage 2x40V (40-0-40) AC (Optional: 12V, 24V, 48V, 110V, 220V, 2x6V, 2x12V, 2x15V, 2x24V, 2x30V, 2x35V, 2x40V, 2x50V, can be customized)
    Secondary Current 83.33A each winding
    No. of Inputs 1 intput
    No. of Outputs

    2 inputs, 4-wire (1 output is available)

    Note: For the transformer with 2 outputs 4-wire, each output provides the same voltage and current level, the sum of 2 output power capacities is equal to the total capacity.

    Frequency 50Hz/60Hz
    Winding Material Copper Wire
    Coil Structure Toroidal
    Efficiency 90%-96%
    No-load Loss <5.96W
    Voltage Strength DC2500V
    Insulation Impedance ≥500MΩ
    Cooling Method Natural air cooling
    Temperature +40℃
    Certification CE, RoHS, ISO, UL
    Warranty 12 months
    External Diameter 220mm
    Height 75mm
    Pedestal 220*220mm
    Mounting Hole Distance 220*220mm
    Weight 18kg
    Package Included 1*Toroidal transformer + 1*Accesorries sets (Nut, Shim, Metal disk, Rubber gaske, Pedestal, Screw)

    Toroidal Transformer Accessories

    toroidal transformer accessories

    Toroidal Transformer Mounting Methods

    toroidal transformer mounting method

    Toroidal Transformer Internal Structure

    toroidal transformer internal structure


    Tips: Select the right core structure of transformer

    The iron core of the toroidal transformer, cold-rolled silicon steel with a thickness of 0.35 mm or less, is seamlessly rolled. The coil is uniformly around the core, and the direction of the magnetic field lines caused by the core almost coincides with the core, so that the eddy current loss generated by the AC current through the coil is minimized. For example, the core loss of E-type transformers exceeds 50%, so as to improve the conversion efficiency of transformation or isolation, thus being often used in switching power supply solutions.

    The core of the toroidal transformer can be deepened without air gap, which is a good choice for switching power supplies or power adapters. The stacking factor can be as high as 95%, and the core magnetic conductance can take 1.5 to 1.8 T. Therefore, the electrical conversion efficiency of the toroidal transformer can reach more than 95%. This is the core structure of the transformer without breath, which can make the reactive current very small, and there is no heat generation in the long-term power situation.
